COST PER HOUR

Management & Merchandising

Total Cost Per Hour of New Track Groups

(a.) (b.) (c.)

10,000 12,000 13,500

Cost to

Replace P & B (Twice) (Once) (None)

Parts 3,000 1,500 0

Labor 1,000 500 0

Cost to Turn P & B (None) (Twice) (Once)

Parts 300 0

Labor 1,000 750

Cost to Replace Shoes (Twice) (Once) (None)

8,000 6,000

Cost to Remove & Install Shoes (Twice) (Once) (Once)

Labor (Inc. W/P&B Rep) (Inc. W/P&B Rep) (Inc. W/Bush Turn)

Hardware 200 100 100

Cost to Regrouser (None) (None) (In Shop) 1500

Cost of Handling & Transportation 400 (Twice) 200 (Once) 200 (Once)

Cost of Downtime 1,000 (Twice) 500 (Once) 500 (Once)

Trade in Value N/A N/A -600

Exchange Value N/A -1600 N/A

Scrap Value -400 N/A N/A

Total 23,200 20,500 15,950

TOTAL Track Group Cost

23,200 20,500 15,950

per hour of effective life ________ = 3.31 ________ = 2.93 _______ = 2.28

7,000 SMU 7,000 SMU 7,000 SMU

This comparison could be expanded to include respective segment, roller, carrier roller,

idler and other wear part costs over the same link life or compared individually over

their own respective and effective total wear lives.
