Caterpillar Custom Track Service Handbook Page 229

Service Handbook

Page of 826

/ 826

Track Links

9W5723 & 24

9W5933 & 34

Depth Gauge High Impact Low Impact Ultrasonic

Inches (mm) % Worn % Worn Inches (mm)

7.12 (181.0) 0 0 1.92 (48.8)

7.10 (180.5) 5 4 1.90 (48.3)

7.08 (180.0) 10 8 1.88 (47.8)

7.06 (179.5) 15 12 1.86 (47.2)

7.04 (179.0) 20 16 1.84 (46.7)

7.02 (178.5) 25 20 1.82 (46.2)

7.00 (178.0) 30 24 1.80 (45.7)

6.98 (177.5) 35 28 1.78 (45.2)

6.96 (177.0) 40 32 1.76 (44.7)

6.94 (176.5) 45 36 1.74 (44.2)

6.92 (176.0) 50 40 1.72 (43.7)

6.90 (175.5) 55 44 1.70 (43.2)

6.88 (175.0) 60 48 1.68 (42.7)

6.86 (174.0) 64 52 1.66 (42.2)

6.84 (173.5) 68 55 1.64 (41.7)

6.82 (173.0) 71 58 1.62 (41.1)

6.80 (172.5) 74 60 1.60 (40.6)

6.78 (172.0) 77 63 1.58 (40.1)

6.76 (171.5) 81 65 1.56 (39.6)

6.74 (171.0) 84 68 1.54 (39.1)

6.72 (170.5) 87 70 1.52 (38.6)

6.70 (170.0) 90 73 1.50 (38.1)

6.68 (169.5) 94 75 1.48 (37.6)

6.66 (169.0) 97 78 1.46 (37.1)

6.64 (168.5) 100 80 1.44 (36.6)

6.62 (168.0) 103 83 1.42 (36.1)

6.60 (167.5) 107 85 1.40 (35.6)

6.58 (167.0) 110 88 1.38 (35.1)

6.56 (166.5) 113 90 1.36 (34.5)

6.54 (166.0) 116 93 1.34 (34.0)

6.52 (165.5) 120 95 1.32 (33.5)

6.50 (165.0) 98 1.30 (33.0)

6.48 (164.5) 100 1.28 (32.5)

6.46 (164.0) 103 1.26 (32.0)

6.44 (163.5) 105 1.24 (31.5)

6.42 (163.0) 108 1.22 (31.0)

6.40 (162.5) 110 1.20 (30.5)

6.38 (162.0) 113 1.18 (30.0)

6.36 (161.5) 115 1.16 (29.5)

6.34 (161.0) 118 1.14 (29.0)

6.32 (160.5) 120 1.12 (28.4)

Undercarriage Code: 207

228

D10 — 10.25" (260.4 mm)

Elevated Sprocket Machines
