Preferred-Side Dozing

or Other Work

Wear rates on the loaded side of a dozer

will increase on all components if only one

side of the machine is used. Wear rates

increase as more power is applied to the

loaded side. More slippage and packing

will occur on the loaded side; this also

increases wear.

Putting more loads and packing onto one

side of the machine may result in up to

twice the wear rate on that side. This wear

rate effect may be balanced by switching

all components from one side to the other.

This should be done when the link and/or

rollers reach 1/2 their potential wear life

on the most worn side.

PARTIALLY CONTROLLABLE VARIABLES

General Information

01.G.I.,M.&M (01-93) 7/11/03 3:40 PM Page 26
