Undercarriage Identification

The easiest way to identify track is to read the part number forged into the link. The fol-

lowing list cross references link part numbers to the correct wear chart pages.

Link Part Wear Chart

Model Pitch Number Pages

943 6.75" (171.5 mm) 7T4173 & 74 436-443

953 6.91" (175.5 mm) 7T4539 & 40 444-458

7.50" (190.5 mm) 106-1625 & 26

229-6909 & 10

963 8.00" (203.2 mm) 7T4645 & 46 460-471

195-6515 & 16

973 8.50" (215.9 mm) 6Y2593 & 94 472-486

7T4657 & 58

6I9239 & 40

428

INTRODUCTION

Hydrostatic Loaders

Computer CTS Codes

Use the following undercarriage codes for computerized CTS:

Undercarriage

Model Code Description

943 322 7T4173-4 Links - Rollers with Retainers

943 323 7T4173-4 Links - Rollers with End Collars

953 343 7T4539-40 Links - Rollers with Retainers

953 344 7T4539-40 Links - Rollers with End Collars

953 345 Rotating Bushing Track - 1061625-6 Links - Rollers with

End Collars

953 346 953 - Hybrid Track - 2296909-10 Links - Rollers with End Collars

963 364 7T4645-6 Links

963 365 Rotating Bushing Track - 8E7405-06 Links

973 373 7T, 9W, 6Y Links - Rollers with Retainers

973 374 7T, 9W, 6Y Links - Rollers with End Collars

973 375 Rotating Bushing Track - 6I9239-40 Links - Rollers with

End Collars

09.Hydro(426-487) 7/14/03 7:31 AM Page 428
