Caterpillar Custom Track Service Handbook Page 547

Service Handbook

Page of 826

/ 826

Track Bushings for Sealed Track

External Wear

Grease Lubricated Track

Allowable Wear

Caliper Lesser Greater Ultrasonic

Inches (mm) % Worn % Worn Inches (mm)

2.75 (69.9) 0 0 0.45 (11.4)

2.74 (69.6) 9 7 0.44 (11.2)

2.73 (69.3) 18 14 0.43 (10.9)

2.72 (69.1) 27 21 0.42 (10.7)

2.71 (68.8) 36 28 0.41 (10.4)

2.70 (68.6) 45 35 0.40 (10.2)

2.69 (68.3) 54 42 0.39 (9.9)

2.68 (68.1) 63 49 0.38 (9.7)

2.67 (67.8) 68 55 0.37 (9.4)

2.66 (67.6) 72 58 0.36 (9.1)

2.65 (67.3) 76 61 0.35 (8.9)

2.64 (67.1) 80 64 0.34 (8.6)

2.63 (66.8) 84 67 0.33 (8.4)

2.62 (66.5) 88 70 0.32 (8.1)

2.61 (66.3) 92 73 0.31 (7.9)

2.60 (66.0) 96 76 0.30 (7.6)

2.59 (65.8) 100 79 0.29 (7.4)

2.58 (65.5) 104 82 0.28 (7.1)

2.57 (65.3) 108 85 0.27 (6.9)

2.56 (65.0) 112 88 0.26 (6.6)

2.55 (64.8) 116 91 0.25 (6.4)

2.54 (64.5) 120 94 0.24 (6.1)

2.53 (64.3) 97 0.23 (5.8)

2.52 (64.0) 100 0.22 (5.6)

2.51 (63.8) 103 0.21 (5.3)

2.50 (63.5) 106 0.20 (5.1)

2.49 (63.2) 109 0.19 (4.8)

2.48 (63.0) 112 0.18 (4.6)

2.47 (62.7) 115 0.17 (4.3)

2.46 (62.5) 118 0.16 (4.1)

2.45 (62.2) 121 0.15 (3.8)

Undercarriage Code: 6091

546

330 — 8.50" (215.9 mm)

Excavators

10.Exc.(488-607) 7/14/03 7:32 AM Page 546
