Caterpillar Custom Track Service Handbook Page 83

Service Handbook

Page of 826

/ 826

TOTAL LIFE SCALE

Management & Merchandising

Maintenance/Rebuild/Replace

Action Symbols

(M) — Measurement or Inspection

Point

(T) — Sealed Track Pin and Bushing

Turn

(Td) — Sealed and Lubricated Track

Dry Bushing Turn

(Tw) — Sealed and Lubricated Track

Wet Bushing Turn

(R-Sw) — Track Roller Swap

(CR-Sw)— Carrier Roller Swap

(I-Sw) — Idler Swap

(REB) — Link, roller, etc. (welding

rebuild)

(REP) — Pin and Bushing or Bushing

and Seal Replacement

(SEG) — Segment Replacement

(REG) — Regrouser Shoe

////// — Unutilized Link or other major

component life remaining

(X) — Destruction of limiting track

component — indicated end

of effective track or other com-

ponent life

(O) — Denoted action taken on

component

01.G.I.,M.&M (01-93) 7/11/03 3:41 PM Page 82
