Caterpillar Custom Track Service Handbook Page 450

Service Handbook

Page of 826

/ 826

Bushings for Rotating Bushing Track

7.50" (190.5 mm) Pitch

Caliper Ultrasonic Depth Gauge

Inches (mm) % Worn Inches (mm) Inches (mm)

2.56 (65.0) 0 0.52 (13.2) 3.19 (81.0)

2.54 (64.5) 4 0.51 (13.0) 3.18 (80.8)

2.52 (64.0) 8 0.50 (12.7) 3.17 (80.5)

2.50 (63.5) 12 0.49 (12.4) 3.16 (80.3)

2.48 (63.0) 16 0.48 (12.2) 3.15 (80.0)

2.46 (62.5) 20 0.47 (11.9) 3.14 (79.8)

2.44 (62.0) 24 0.46 (11.7) 3.13 (79.5)

2.42 (61.5) 28 0.45 (11.4) 3.12 (79.2)

2.40 (61.0) 32 0.44 (11.2) 3.11 (79.0)

2.38 (60.5) 36 0.43 (10.9) 3.10 (78.7)

2.36 (59.9) 40 0.42 (10.7) 3.09 (78.5)

2.34 (59.4) 42 0.41 (10.4) 3.08 (78.2)

2.32 (58.9) 44 0.40 (10.2) 3.07 (78.0)

2.30 (58.4) 46 0.39 (9.9) 3.06 (77.7)

2.28 (57.9) 48 0.38 (9.7) 3.05 (77.5)

2.26 (57.4) 50 0.37 (9.4) 3.04 (77.2)

2.24 (56.9) 52 0.36 (9.1) 3.03 (77.0)

2.22 (56.4) 54 0.35 (8.9) 3.02 (76.7)

2.20 (55.9) 56 0.34 (8.6) 3.01 (76.5)

2.18 (55.4) 58 0.33 (8.4) 3.00 (76.2)

2.16 (54.9) 60 0.32 (8.1) 2.99 (75.9)

2.14 (54.4) 62 0.31 (7.9) 2.98 (75.7)

2.12 (53.8) 64 0.30 (7.6) 2.97 (75.4)

2.10 (53.3) 66 0.29 (7.4) 2.96 (75.2)

2.08 (52.8) 68 0.28 (7.1) 2.95 (74.9)

2.06 (52.3) 70 0.27 (6.9) 2.94 (74.7)

2.04 (51.8) 72 0.26 (6.6) 2.93 (74.4)

2.02 (51.3) 74 0.25 (6.3) 2.92 (74.2)

2.00 (50.8) 76 0.24 (6.1) 2.91 (73.9)

1.98 (50.3) 78 0.23 (5.8) 2.90 (73.7)

1.96 (49.8) 80 0.22 (5.6) 2.89 (73.4)

1.94 (49.3) 82 0.21 (5.3) 2.88 (73.2)

1.92 (48.8) 84 0.20 (5.1) 2.87 (72.9)

1.90 (48.3) 86 0.19 (4.8) 2.86 (72.6)

1.88 (47.8) 88 0.18 (4.6) 2.85 (72.4)

1.86 (47.2) 90 0.17 (4.3) 2.84 (72.1)

1.84 (46.7) 92 0.16 (4.1) 2.83 (71.9)

1.82 (46.2) 94 0.15 (3.8) 2.82 (71.6)

1.80 (45.7) 96 0.14 (3.6) 2.81 (71.4)

1.78 (45.2) 98 0.13 (3.3) 2.80 (71.1)

1.76 (44.7) 100 0.12 (3.0) 2.79 (70.9)

1.74 (44.2) 102 0.11 (2.8) 2.78 (70.6)

1.72 (43.7) 104 0.10 (2.5) 2.77 (70.4)

1.70 (43.2) 106 0.09 (2.3) 2.76 (70.1)

1.68 (42.7) 108 0.08 (2.0) 2.75 (69.9)

1.66 (42.2) 110 0.07 (1.8) 2.74 (69.6)

1.64 (41.7) 112 0.06 (1.5) 2.73 (69.3)

1.62 (41.1) 114 0.05 (1.3) 2.72 (69.1)

1.60 (40.6) 116 0.04 (1.0) 2.71 (68.8)

1.58 (40.1) 118 0.03 (0.8) 2.70 (68.6)

1.56 (39.6) 120 0.02 (0.5) 2.69 (68.3)

Undercarriage Code: 345

449

Hydrostatic Loaders

953 — 6.91" (175.5 mm), 7.50" (190.5 mm)

09.Hydro(426-487) 7/14/03 7:32 AM Page 449
