Variables That Affect

Undercarriage Life

The variables that determine complete

undercarriage system life and wear balance

between components can be divided into

three major groupings. The first are those

which, to a great extent, are controllable.

Controllable variables include track tension

adjustment (controlled by user operating

and/or maintenance personnel), shoe width

(controlled by user operating and purchas-

ing personnel) and on some models, align-

ment (controlled by user and/or dealer

service personnel).

The second major group, non-controllable

variables, discussed later in this major

section include those life determining

factors which are “givens.” They come

with the job. They are 100 percent deter-

mined by the underfoot conditions and

include impact, abrasiveness, packing,

moisture, terrain and even application,

meaning what the machine is doing.

The final major group is sometimes called

partially controllable variables and mainly

involve machine operator controllable

events such as “habits.”

A thorough knowledge of each of the

elements of all these three major groups is

essential if the CTS expert is going to be

able to not only explain “what has hap-

pened,” but also “what could be expected to

happen,” especially as any of these variables

were to change. Awareness of the relative

interplay between these variables on the

final wear or structural life of specific com-

ponents, and even on the system is so

important that their discussion has been

placed at the front of this book. To use the

rest of the book before understanding these

would be counterproductive.

Controllable Variables

Controllable variables that affect undercar-

riage life must be separated out for dis-

cussion because, in the case of at least the

first two, they can have major economic

effect on the operation of undercarriage

systems.

Track adjustment can have a very large

effect on external bushing life, even to the

extent of deciding whether a costly turn

will or will not be required to use up the

link-roller system. Track tension can also

affect track seal integrity. Track adjust-

ment is controllable because the user can

change it.

Shoe width, for which a detailed discus-

sion follows, is controllable because the

user, with your advice, chooses which

shoe to order on his new machine and/or

changes to when the machine changes

tracks or even jobs. Shoe width as you will

learn can effect such widely ranging items

as track seal and lubricant integrity to link

cracking to roller flange wear to bushing

wear rate.

Alignment, the third and least critical

controllable variable is discussed here

because, particularly on low sprocket

machines, it is wrongly blamed as a cause

for many symptoms. It is beneficial to

know how misalignment does and does

not affect wear patterns so you can better

identify the real cause, controllable or not.

A short discussion on track-excited

vibration is also placed in this area even

though it is only controllable at machine

design time.

Track Adjustment

Although the method of measuring the

reference sag and adjusting the track varies

by machine type, the importance for these

different machine types does not. As dis-

cussed earlier, track over-tightening can

drastically affect external bushing life

(increasing wear rate as much as three

times) and for this reason alone is listed fre-

quently as a “cause” or “accelerator” under

the wear and structural problems section for

many components. See separate machine

sections for complete instructions on track

adjustment.

General Information

UNDERCARRIAGE LIFE VARIABLES — CONTROLLABLE VARIABLES
