Caterpillar Custom Track Service Handbook Page 473

Service Handbook

Page of 826

/ 826

Track Links

6Y2593 & 94

7T4657 & 58

Depth Gauge Ultrasonic

Inches (mm) % Worn Inches (mm)

5.23 (133.0) 0 1.64 (41.7)

5.21 (132.5) 4 1.62 (41.1)

5.19 (132.0) 8 1.60 (40.6)

5.17 (131.5) 12 1.58 (40.1)

5.15 (131.0) 16 1.56 (39.6)

5.13 (130.5) 20 1.54 (39.1)

5.11 (130.0) 24 1.52 (38.6)

5.09 (129.5) 28 1.50 (38.1)

5.07 (129.0) 32 1.48 (37.6)

5.05 (128.5) 36 1.46 (37.1)

5.03 (128.0) 40 1.44 (36.6)

5.01 (127.5) 44 1.42 (36.1)

4.99 (126.5) 48 1.40 (35.6)

4.97 (126.0) 52 1.38 (35.1)

4.95 (125.5) 56 1.36 (34.5)

4.93 (125.0) 60 1.34 (34.0)

4.91 (124.5) 64 1.32 (33.5)

4.89 (124.0) 68 1.30 (33.0)

4.87 (123.5) 72 1.28 (32.5)

4.85 (123.0) 76 1.26 (32.0)

4.83 (122.5) 80 1.24 (31.5)

4.81 (122.0) 84 1.22 (31.0)

4.79 (121.5) 88 1.20 (30.5)

4.77 (121.0) 92 1.18 (30.0)

4.75 (120.5) 96 1.16 (29.5)

4.73 (120.0) 100 1.14 (29.0)

4.71 (119.5) 103 1.12 (28.4)

4.69 (119.0) 106 1.10 (27.9)

4.67 (118.5) 109 1.08 (27.4)

4.65 (118.0) 112 1.06 (26.9)

4.63 (117.5) 115 1.04 (26.4)

4.61 (117.0) 118 1.02 (25.9)

4.59 (116.5) 121 1.00 (25.4)

Undercarriage Code: 373, 374

472

Hydrostatic Loaders

973 — 8.50" (215.9 mm)

09.Hydro(426-487) 7/14/03 7:32 AM Page 472
