Track Rollers

Extended Life Rollers

Use with 7T Links

Caliper Depth Gauge Ultrasonic

Inches (mm) % Worn Inches (mm) Inches (mm)

8.38 (213.0) 0 0.57 (14.5) 2.07 (52.6)

8.34 (212.0) 4 0.59 (15.0) 2.05 (52.1)

8.30 (211.0) 8 0.61 (15.5) 2.03 (51.6)

8.26 (210.0) 12 0.63 (16.0) 2.01 (51.1)

8.22 (209.0) 16 0.65 (16.5) 1.99 (50.5)

8.18 (208.0) 20 0.67 (17.0) 1.97 (50.0)

8.14 (207.0) 24 0.69 (17.5) 1.95 (49.5)

8.10 (205.5) 28 0.71 (18.0) 1.93 (49.0)

8.06 (204.5) 32 0.73 (18.5) 1.91 (48.5)

8.02 (203.5) 36 0.75 (19.0) 1.89 (48.0)

7.98 (202.5) 40 0.77 (19.5) 1.87 (47.5)

7.94 (201.5) 44 0.79 (20.0) 1.85 (47.0)

7.90 (200.5) 48 0.81 (20.5) 1.83 (46.5)

7.86 (199.5) 52 0.83 (21.0) 1.81 (46.0)

7.82 (198.5) 56 0.85 (21.5) 1.79 (45.5)

7.78 (197.5) 60 0.87 (22.0) 1.77 (45.0)

7.74 (196.5) 64 0.89 (22.5) 1.75 (44.5)

7.70 (195.5) 66 0.91 (23.0) 1.73 (43.9)

7.66 (194.5) 68 0.93 (23.5) 1.71 (43.4)

7.62 (193.5) 70 0.95 (24.0) 1.69 (42.9)

7.58 (192.5) 72 0.97 (24.5) 1.67 (42.4)

7.54 (191.5) 74 0.99 (25.0) 1.65 (41.9)

7.50 (190.5) 76 1.01 (25.5) 1.63 (41.4)

7.46 (189.5) 78 1.03 (26.0) 1.61 (40.9)

7.42 (188.5) 80 1.05 (26.5) 1.59 (40.4)

7.38 (187.5) 82 1.07 (27.0) 1.57 (39.9)

7.34 (186.5) 84 1.09 (27.5) 1.55 (39.4)

7.30 (185.5) 86 1.11 (28.0) 1.53 (38.9)

7.26 (184.5) 88 1.13 (28.5) 1.51 (38.4)

7.22 (183.5) 90 1.15 (29.0) 1.49 (37.8)

7.18 (182.5) 92 1.17 (29.5) 1.47 (37.3)

7.14 (181.5) 94 1.19 (30.0) 1.45 (36.8)

7.10 (180.5) 96 1.21 (30.5) 1.43 (36.3)

7.06 (179.5) 98 1.23 (31.0) 1.41 (35.8)

7.02 (178.5) 100 1.25 (32.0) 1.39 (35.3)

6.98 (177.5) 102 1.27 (32.5) 1.37 (34.8)

6.94 (176.5) 104 1.29 (33.0) 1.35 (34.3)

6.90 (175.5) 106 1.31 (33.5) 1.33 (33.8)

6.86 (174.0) 108 1.33 (34.0) 1.31 (33.3)

6.82 (173.0) 110 1.35 (34.5) 1.29 (32.8)

6.78 (172.0) 112 1.37 (35.0) 1.27 (32.3)

6.74 (171.0) 114 1.39 (35.5) 1.25 (31.8)

6.70 (170.0) 116 1.41 (36.0) 1.23 (31.2)

6.66 (169.0) 118 1.43 (36.5) 1.21 (30.7)

6.62 (168.0) 120 1.45 (37.0) 1.19 (30.2)

Flange diameter is 9.53" (242 mm)

Undercarriage Code: 105, 131, 332

323

D5, 955, 951, 561 — 6.91" (175.5 mm)

Low Sprocket Machines

05.Low(246-325) 7/11/03 3:52 PM Page 323
