Caterpillar Custom Track Service Handbook Page 89

Service Handbook

Page of 826

/ 826

COST PER HOUR

Management & Merchandising

The link life to service point and destruction point is shown for reference purposes only

and is not included in the cost per hour comparison.

a. Single grouser shoe run to destruction and replaced twice to equal link:

b. Extreme service shoe run to destruction and replaced once to equal link:

c. Extreme service shoe run to service limit, regrouser then run to destruction to equal

link:

TOTAL COST PER HOUR AT (a.) (b.) (c.)

INITIAL COST OF SHOES

(as part of new track group) 4000 6000 6000

Cost to remove and install (Twice) (Once) (None)

Labor 400 200 200

Hardware 200 100 0

Cost of Replacement Shoes 8000 6000 (None)

Cost of Regrouser (None) (None) 2000

Cost of Track Group

Handling & Transportation 400 (Twice) 200 (Once) 0

Cost of Downtime 500 (Twice) 300 (Once) 400 (Once)

Trade-in Value N/A N/A -300

Exchange Value N/A -800 N/A

Scrap Value -200 N/A N/A

______ ______ _____

Total 13,300 12,000 8,300

13,300 12,000 8,300

Total Cost/Hr. ______ = 1.90 ______ = 1.71 _____ = 1.19

of Effective Life

7,000 7,000 7,000

0 1000 2000 3000 4000 5000 6000

7000

8000

TRADE-

REG

REP

EXCHANGE

REP

SCRAP

REP

01.G.I.,M.&M (01-93) 7/11/03 3:41 PM Page 88
