Sprocket Bolt Torque Specifications

Bolt Additional

Model Size Torque Turn

943 5/8" 130 ± 30 ft. lb. +1/3 turn

175 ± 40 Nm

953 M16 130 ± 30 ft. lb. +1/3 turn

175 ± 40 Nm

963 5/8" 130 ± 30 ft. lb. +1/3 turn

175 ± 40 Nm

973 3/4" 220 ± 40 ft. lb. +1/3 turn

300 ± 50 Nm

Use the torque-turn tightening method on

page 70.

Guards

See page 71 for detailed information on track

guiding guards and track roller guards.

Sprocket Guards — Sprocket guards

shield undercarriage components and

reduce the area between the sprocket and

roller frame where underfoot material can

enter and/or build up. The reduction of

material entering the undercarriage system

decreases sprocket, bushing, link and track

roller wear. Sprocket guards are now

standard on new machines and can be

retrofitted to earlier hydrostatic loaders.

Sprocket guards are most effective in

abrasive and high packing conditions.

Idler Guards — Idler Guards enclose the

open area behind the idler protecting the

idler, recoil rod and link assembly from

increased wear caused by entrapped under-

foot material.

Idler guards are an attachment on new

machines and can be retrofitted to earlier

hydrostatic loaders. These guards are most

effective in demolition debris, rock condi-

tions and sanitary landfill (all with 1" to 4"

size material).

432

COMPONENTS

Hydrostatic Loaders
