Components

Each component has individual measure-

ment techniques, wear limits, wear charts,

rebuildability criteria, wear patterns and

structural problems. The general informa-

tion for each component is covered in the

following section. Specific additions and

exceptions are covered in the individual

product sections.

Percent Worn Charts

The percent worn charts section of this

handbook translate direct component

measurements into percent worn for

Caterpillar parts only.

Remember — all percent worn figures

shown are percent of time used and not

percent of material used. This allows them

to be used to directly calculate or project

total potential time (or life left) to the

service limit. These charts consider the

slower rate of wear when the hardened

case is still there and the faster rate of

wear that occurs when softer material is

exposed. In some cases they also take into

account different expected wear rates after

the service limit. In most cases they are

not “straight-line” relationships.

Charts are provided for high and low impact

applications where applicable. Measure-

ments corresponding to 100 percent worn

(the service limit) are underlined.

In most cases, service limit projections

made from less than 30 percent worn can

not be considered accurate. However, such

projections can be used to determine call

back dates for remeasuring.

Percentages above 100 percent have been

provided so projections to 120 percent

worn can be calculated. Backward projec-

tions to service limit (100 percent) can

also be made to determine when the

service limit was reached. The extent of

percentages shown beyond 100 percent

has no particular significance.

Guidance for the selection of high, moderate

or low impact and lesser or greater allow-

able wear charts is provided at the front of

each section of wear charts.

A separate discussion under each component

sub-section (links, bushings, etc.) describes

how the service limit was derived and the

risk involved when the component is worn

past that point.

NOTE: Competitive undercarriage inspec-

tion, wear life and maintenance/rebuild

projection cannot be determined from

information contained in the handbook

because of a lack of information about

design, expected wear rates and service

limits even when some important dimen-

sions are similar.
