Bushings for Sealed Track

External Wear

Sealed Track

Allowable Wear

Caliper Lesser Greater Ultrasonic

Inches (mm) % Worn % Worn Inches (mm)

2.70 (68.6) 0 0 0.42 (10.7)

2.69 (68.3) 9 7 0.41 (10.4)

2.68 (68.1) 18 14 0.40 (10.2)

2.67 (67.8) 27 21 0.39 (9.9)

2.66 (67.6) 36 28 0.38 (9.7)

2.65 (67.3) 45 35 0.37 (9.4)

2.64 (67.1) 54 42 0.36 (9.1)

2.63 (66.8) 63 49 0.35 (8.9)

2.62 (66.5) 72 56 0.34 (8.6)

2.61 (66.3) 81 63 0.33 (8.4)

2.60 (66.0) 88 70 0.32 (8.1)

2.59 (65.8) 92 73 0.31 (7.9)

2.58 (65.5) 96 76 0.30 (7.6)

2.57 (65.3) 100 79 0.29 (7.4)

2.56 (65.0) 104 82 0.28 (7.1)

2.55 (64.8) 108 85 0.27 (6.9)

2.54 (64.5) 112 88 0.26 (6.6)

2.53 (64.3) 116 91 0.25 (6.4)

2.52 (64.0) 120 94 0.24 (6.1)

2.51 (63.8) 97 0.23 (5.8)

2.50 (63.5) 100 0.22 (5.6)

2.49 (63.2) 103 0.21 (5.3)

2.48 (63.0) 106 0.20 (5.1)

2.47 (62.7) 109 0.19 (4.8)

2.46 (62.5) 112 0.18 (4.6)

2.45 (62.2) 115 0.17 (4.3)

2.44 (62.0) 118 0.16 (4.1)

2.43 (61.7) 121 0.15 (3.8)

Undercarriage Code: 609

547

330 — 8.50" (215.9 mm)

Excavators

10.Exc.(488-607) 7/14/03 7:32 AM Page 547
