Chart 3

Track Roller Frame Extension Specifications

Maximum Length of Exposed Tube

Model Serial Numbers Inches Millimeters

D4H 3.9 (100)

D5H 4.4 (112)

D5M LGP, D5N LGP 3.5 (88.5)

D5M XL, D5N XL 3.6 (91.7)

D6M LGP, D5N LGP 4.3 (108.2)

D6M XL, D5N XL 4.0 (102.4)

D6H XL 6.0 (153.5)

D6H LGP 6.2 (156.8)

D6H, D6H XR 6.4 (161.8)

D6R XW (AEP) 5.7 (144.2)

D6R XL (4MN00504 & UP) (5LN02766 & UP) 5.7 (144.2)

D6R XL (4MN00001-4MN00503) (5LN00001-5LN02765) 6.0 (153.5)

D6R LGP (8LN0529 & UP) (9PN1579 & UP) (ACJ) (ADE) 5.6 (142.5)

D6R LGP (8LN0001-8LN0528) (9PN0001-9PN1578) 6.0 (151.8)

D6R XR (6JN00416 & UP) (7KN00451 & UP) 5.8 (147.5)

D6R XR (6JN00001-00415) (7KN0000-7KN00450) 6.2 (156.8)

D6R (2YN00545 & UP) (3ZN00763 & UP) (AFM) (AEM) 5.8 (147.5)

D6R (2YN00001-2YN00544) (3ZN00001-3ZN00762) 6.2 (156.8)

D7H LGP 5.0 (127)

D7H, D7H XR 5.0 (126)

D7R LGP 5.4 (136.5)

D7R, D7R XR 5.4 (136)

D8L 6.5 (165)

D8N (9TC) (5TC) 5.6 (142)

D8R (6YZ) (7XM05094 & UP) (7XM) 6.0 (152)

D8R (7XM00001 - 7XM05093) 5.6 (142)

D9L 6.3 (160)

D9N 5.9 (150)

D9R (8BL01422 - UP) (7TL01212 - UP) 7.4 (189)

D9R (8BL00001 - 8BL01421) (7TL00001 - 7TL01211) 5.9 (150)

D10 7.0 (178)

D10N (2YD00516-UP) 6.8 (173)

D10N (2YD00001-2YD00515) 5.8 (148)

D10R 7.6 (194)

D11N 7.0 (178)

D11R 7.8 (198)

109

TRACK ADJUSTMENTS

Elevated Sprocket Machines
