Bushings for Sealed & Lubricated Track

Allowable Wear

Caliper Lesser Greater Ultrasonic Depth Gauge

Inches (mm) % Worn % Worn Inches (mm) Inches (mm)

4.32 (109.7) 0 0 0.82 (20.8) 5.62 (142.7)

4.31 (109.5) 4 3 0.81 (20.6) 5.61 (142.5)

4.30 (109.2) 8 6 0.80 (20.3) 5.60 (142.2)

4.29 (109.0) 12 9 0.79 (20.1) 5.59 (142.0)

4.28 (108.7) 16 12 0.78 (19.8) 5.58 (141.7)

4.27 (108.5) 20 15 0.77 (19.6) 5.57 (141.5)

4.26 (108.2) 24 18 0.76 (19.3) 5.56 (141.2)

4.25 (108.0) 28 21 0.75 (19.1) 5.55 (141.0)

4.24 (107.7) 32 24 0.74 (18.8) 5.54 (140.7)

4.23 (107.4) 36 27 0.73 (18.5) 5.53 (140.5)

4.22 (107.2) 40 30 0.72 (18.3) 5.52 (140.2)

4.21 (106.9) 43 33 0.71 (18.0) 5.51 (140.0)

4.20 (106.7) 46 36 0.70 (17.8) 5.50 (139.7)

4.19 (106.4) 49 39 0.69 (17.5) 5.49 (139.4)

4.18 (106.2) 52 42 0.68 (17.3) 5.48 (139.2)

4.17 (105.9) 55 45 0.67 (17.0) 5.47 (138.9)

4.16 (105.7) 58 48 0.66 (16.8) 5.46 (138.7)

4.15 (105.4) 61 51 0.65 (16.5) 5.45 (138.4)

4.14 (105.2) 64 54 0.64 (16.3) 5.44 (138.2)

4.13 (104.9) 67 57 0.63 (16.0) 5.43 (137.9)

4.12 (104.6) 70 60 0.62 (15.7) 5.42 (137.7)

4.11 (104.4) 73 62 0.61 (15.5) 5.41 (137.4)

4.10 (104.1) 76 64 0.60 (15.2) 5.40 (137.2)

4.09 (103.9) 79 66 0.59 (15.0) 5.39 (136.9)

4.08 (103.6) 82 68 0.58 (14.7) 5.38 (136.7)

4.07 (103.4) 85 70 0.57 (14.5) 5.37 (136.4)

4.06 (103.1) 88 72 0.56 (14.2) 5.36 (136.1)

4.05 (102.9) 91 74 0.55 (14.0) 5.35 (135.9)

4.04 (102.6) 94 76 0.54 (13.7) 5.34 (135.6)

4.03 (102.4) 97 78 0.53 (13.5) 5.33 (135.4)

4.02 (102.1) 100 80 0.52 (13.2) 5.32 (135.1)

4.01 (101.9) 103 82 0.51 (13.0) 5.31 (134.9)

4.00 (101.6) 106 84 0.50 (12.7) 5.30 (134.6)

3.99 (101.3) 109 86 0.49 (12.4) 5.29 (134.4)

3.98 (101.1) 112 88 0.48 (12.2) 5.28 (134.1)

3.97 (100.8) 115 90 0.47 (11.9) 5.27 (133.9)

3.96 (100.6) 118 92 0.46 (11.7) 5.26 (133.6)

3.95 (100.3) 121 94 0.45 (11.4) 5.25 (133.4)

3.94 (100.1) 96 0.44 (11.2) 5.24 (133.1)

3.93 (99.8) 98 0.43 (10.9) 5.23 (132.8)

3.92 (99.6) 100 0.42 (10.7) 5.22 (132.6)

3.91 (99.3) 102 0.41 (10.4) 5.21 (132.3)

3.90 (99.1) 104 0.40 (10.2) 5.20 (132.1)

3.89 (98.8) 106 0.39 (9.9) 5.19 (131.8)

3.88 (98.6) 108 0.38 (9.7) 5.18 (131.6)

3.87 (98.3) 110 0.37 (9.4) 5.17 (131.3)

3.86 (98.0) 112 0.36 (9.1) 5.16 (131.1)

3.85 (97.8) 114 0.35 (8.9) 5.15 (130.8)

3.84 (97.5) 116 0.34 (8.6) 5.14 (130.6)

3.83 (97.3) 118 0.33 (8.4) 5.13 (130.3)

3.82 (97.0) 120 0.32 (8.1) 5.12 (130.0)

NOTE: DO NOT USE DEPTH GAUGE UNTIL BUSHINGS HAVE BEEN “TURNED.”

Undercarriage Code: 220, 2203, 221, 2213

238

D11N, D11R — 12.50" (317.5 mm)
