Bushings for Sealed & Lubricated Track

Use with 6Y9261 & 62 Links and Large Stepped Bushings

Allowable Wear

Caliper Lesser Greater Ultrasonic Depth Gauge

Inches (mm) % Worn % Worn Inches (mm) Inches (mm)

2.39 (60.7) 0 0 0.51 (13.0) 2.88 (73.2)

2.38 (60.5) 5 4 0.50 (12.7) 2.87 (72.9)

2.37 (60.2) 10 8 0.49 (12.4) 2.86 (72.6)

2.36 (59.9) 15 12 0.48 (12.2) 2.85 (72.4)

2.35 (59.7) 20 16 0.47 (11.9) 2.84 (72.1)

2.34 (59.4) 25 20 0.46 (11.7) 2.83 (71.9)

2.33 (59.2) 30 24 0.45 (11.4) 2.82 (71.6)

2.32 (58.9) 35 28 0.44 (11.2) 2.81 (71.4)

2.31 (58.7) 40 32 0.43 (10.9) 2.80 (71.1)

2.30 (58.4) 45 36 0.42 (10.7) 2.79 (70.9)

2.29 (58.2) 50 40 0.41 (10.4) 2.78 (70.6)

2.28 (57.9) 55 42 0.40 (10.2) 2.77 (70.4)

2.27 (57.7) 60 44 0.39 (9.9) 2.76 (70.1)

2.26 (57.4) 65 46 0.38 (9.7) 2.75 (69.9)

2.25 (57.2) 68 48 0.37 (9.4) 2.74 (69.6)

2.24 (56.9) 70 50 0.36 (9.1) 2.73 (69.3)

2.23 (56.6) 72 52 0.35 (8.9) 2.72 (69.1)

2.22 (56.4) 74 54 0.34 (8.6) 2.71 (68.8)

2.21 (56.1) 76 56 0.33 (8.4) 2.70 (68.6)

2.20 (55.9) 78 58 0.32 (8.1) 2.69 (68.3)

2.19 (55.6) 80 60 0.31 (7.9) 2.68 (68.1)

2.18 (55.4) 82 62 0.30 (7.6) 2.67 (67.8)

2.17 (55.1) 84 64 0.29 (7.4) 2.66 (67.6)

2.16 (54.9) 86 66 0.28 (7.1) 2.65 (67.3)

2.15 (54.6) 88 68 0.27 (6.9) 2.64 (67.1)

2.14 (54.4) 90 70 0.26 (6.6) 2.63 (66.8)

2.13 (54.1) 92 72 0.25 (6.3) 2.62 (66.5)

2.12 (53.8) 94 74 0.24 (6.1) 2.61 (66.3)

2.11 (53.6) 96 76 0.23 (5.8) 2.60 (66.0)

2.10 (53.3) 98 78 0.22 (5.6) 2.59 (65.8)

2.09 (53.1) 100 80 0.21 (5.3) 2.58 (65.5)

2.08 (52.8) 102 82 0.20 (5.1) 2.57 (65.3)

2.07 (52.6) 104 84 0.19 (4.8) 2.56 (65.0)

2.06 (52.3) 106 86 0.18 (4.6) 2.55 (64.8)

2.05 (52.1) 108 88 0.17 (4.3) 2.54 (64.5)

2.04 (51.8) 110 90 0.16 (4.1) 2.53 (64.3)

2.03 (51.6) 112 92 0.15 (3.8) 2.52 (64.0)

2.02 (51.3) 114 94 0.14 (3.6) 2.51 (63.8)

2.01 (51.1) 116 96 0.13 (3.3) 2.50 (63.5)

2.00 (50.8) 118 98 0.12 (3.0) 2.49 (63.2)

1.99 (50.5) 120 100 0.11 (2.8) 2.48 (63.0)

1.98 (50.3) 102 0.10 (2.5) 2.47 (62.7)

1.97 (50.0) 104 0.09 (2.3) 2.46 (62.5)

1.96 (49.8) 106 0.08 (2.0) 2.45 (62.2)

1.95 (49.5) 108 0.07 (1.8) 2.44 (62.0)

1.94 (49.3) 110 0.06 (1.5) 2.43 (61.7)

1.93 (49.0) 112 0.05 (1.3) 2.42 (61.5)

1.92 (48.8) 114 0.04 (1.0) 2.41 (61.2)

1.91 (48.5) 116 0.03 (0.8) 2.40 (61.0)

1.90 (48.3) 118 0.02 (0.5) 2.39 (60.7)

1.89 (48.0) 120 0.01 (0.3) 2.38 (60.5)

Undercarriage Code: 13402, 13502, 13532

297

D5G, D5C, 939 — 6.75" (171.5 mm)

Low Sprocket Machines

05.Low(246-325) 7/11/03 3:52 PM Page 297
