Caterpillar Custom Track Service Handbook Page 491

Service Handbook
490
INTRODUCTION
Excavators
Undercarriage Identification
The easiest way to identify track is to read the part number forged into the link. The fol-
lowing list cross-references link part numbers to the correct percent worn chart pages.
Link Part Wear Chart
Model Pitch Number Pages
307, 308 5.31" 136-2404 & 10 498-507
6.06" 093-1969 & 70
3A9614 & 15
311, 312, 313, 314 6.75" 4I7475 & 76 508-514
315, 317, 318, 320, 7.50" 9W3137 & 38 516-529
322, 320 FM 106-1625 & 26
320S, 322 FM, 8.00" 6Y1607 & 08 530-542
325, 325 FM 8E7405 & 06
330 8.50" 6Y2589 & 90 544-555
330 FM, 345 8.50" 150-4748 & 49 556-564
130-5333 & 34
209-6383 & 84
350 9.00" 8E6091 & 92 566-573
365, 375, 385, 5080, 5090 10.25" 142-1803 & 04 574-583
6Y6721 & 22
5110 10.25" 9W5933 & 34 584-591
5130 12.50" 6I8643 & 44 592-600
6T8049 & 50
5230 14.90" 185-9377 & 78 602-606
205, 211, 213 6.75" 9K6628 & 29 608-615
215 6.75" 9K6628 & 29 616-628
225, 219, 215S.A., 7.50" 7T4043 & 44 630-644
FB221, FB217, DL221 3P7153 & 54
225 6.75" 9K6628 & 29 646-655
227, 229, 231, 8.00" 3P1112 & 13 656-665
225S.A., LL225
235, LL235 8.50" 8E8641 & 42 666-682
130-5333 & 34
8S2589 & 90
7T9823 & 24
235 8.00" 3P1112 & 13 684-691
245 10.25" 9S1927 & 28 692-701
245 9.00" 8K4754 & 56 702-709
9G6083 & 84
E70B 5.31" 093-1969 & 70 710-718
E110B, E120B 6.75" 4I7475 & 76 720-726
E140 6.75" 093-1978 & 77 728-734
E180, EL180 6.91" 095-7130 736-742
093-1979
E200B, EL200B 7.50" 9W3137 & 38 744-750
EL240B, E240B, 7.50" 9W3137 & 38 752-759
EL240, E240 0965252 & 58
E300B, EL300B, EL300 8.00" 096-0263 & 64 760-767
E300 7.50" 096-5252 & 58 768-775
E450 8.50" 096-9944 & 46 776-782
E650 9.00" 093-1984 & 85 784-790
10.Exc.(488-607) 7/14/03 7:32 AM Page 490
