Caterpillar Custom Track Service Handbook Page 370

Service Handbook

Page of 826

/ 826

Track Bushings for Sealed Track

External Wear

Allowable Wear

Caliper Lesser Greater Ultrasonic

Inches (mm) % Worn % Worn Inches (mm)

3.04 (77.2) 0 0 0.49 (12.4)

3.03 (77.0) 10 7 0.48 (12.2)

3.02 (76.7) 20 14 0.47 (11.9)

3.01 (76.5) 30 21 0.46 (11.7)

3.00 (76.2) 40 28 0.45 (11.4)

2.99 (75.9) 50 35 0.44 (11.2)

2.98 (75.7) 60 42 0.43 (10.9)

2.97 (75.4) 70 49 0.42 (10.7)

2.96 (75.2) 80 56 0.41 (10.4)

2.95 (74.9) 90 63 0.40 (10.2)

2.94 (74.7) 95 70 0.39 (9.9)

2.93 (74.4) 100 77 0.38 (9.7)

2.92 (74.2) 105 82 0.37 (9.4)

2.91 (73.9) 110 85 0.36 (9.1)

2.90 (73.7) 115 88 0.35 (8.9)

2.89 (73.4) 120 91 0.34 (8.6)

2.88 (73.2) 94 0.33 (8.4)

2.87 (72.9) 97 0.32 (8.1)

2.86 (72.6) 100 0.31 (7.9)

2.85 (72.4) 103 0.30 (7.6)

2.84 (72.1) 106 0.29 (7.4)

2.83 (71.9) 109 0.28 (7.1)

2.82 (71.6) 112 0.27 (6.9)

2.81 (71.4) 115 0.26 (6.6)

2.80 (71.1) 118 0.25 (6.3)

2.79 (70.9) 121 0.24 (6.1)

Undercarriage Code: 175, 390

369

D8, 983 — 9.00" (228.6 mm)

Low Sprocket Machines

07.Low(348-387) 7/14/03 7:30 AM Page 369
