Caterpillar Custom Track Service Handbook Page 587

Service Handbook

Page of 826

/ 826

586

Excavators

5110 — 10.25" (260.4 mm)

Bushings for Sealed Track

External Wear

Caliper Ultrasonic

Inches (mm) % Worn Inches (mm)

3.81 (96.8) 0 0.76 (19.3)

3.80 (96.5) 5 0.75 (19.1)

3.79 (96.3) 10 0.74 (18.8)

3.78 (96.0) 15 0.73 (18.5)

3.77 (95.8) 20 0.72 (18.3)

3.76 (95.5) 25 0.71 (18.0)

3.75 (95.3) 30 0.70 (17.8)

3.74 (95.0) 35 0.69 (17.5)

3.73 (94.7) 40 0.68 (17.3)

3.72 (94.5) 45 0.67 (17.0)

3.71 (94.2) 50 0.66 (16.8)

3.70 (94.0) 55 0.65 (16.5)

3.69 (93.7) 60 0.64 (16.3)

3.68 (93.5) 65 0.63 (16.0)

3.67 (93.2) 68 0.62 (15.7)

3.66 (93.0) 70 0.61 (15.5)

3.65 (92.7) 72 0.60 (15.2)

3.64 (92.5) 74 0.59 (15.0)

3.63 (92.2) 76 0.58 (14.7)

3.62 (91.9) 78 0.57 (14.5)

3.61 (91.7) 80 0.56 (14.2)

3.60 (91.4) 82 0.55 (14.0)

3.59 (91.2) 84 0.54 (13.7)

3.58 (90.9) 86 0.53 (13.5)

3.57 (90.7) 88 0.52 (13.2)

3.56 (90.4) 90 0.51 (13.0)

3.55 (90.2) 92 0.50 (12.7)

3.54 (89.9) 94 0.49 (12.4)

3.53 (89.7) 96 0.48 (12.2)

3.52 (89.4) 98 0.47 (11.9)

3.51 (89.2) 100 0.46 (11.7)

3.50 (88.9) 102 0.45 (11.4)

3.49 (88.6) 104 0.44 (11.2)

3.48 (88.4) 106 0.43 (10.9)

3.47 (88.1) 108 0.42 (10.7)

3.46 (87.9) 110 0.41 (10.4)

3.45 (87.6) 112 0.40 (10.2)

3.44 (87.4) 114 0.39 (9.9)

3.43 (87.1) 116 0.38 (9.7)

3.42 (86.9) 118 0.37 (9.4)

3.41 (86.6) 120 0.36 (9.1)

Undercarriage Code: 665
