Edition Fifteen is a comprehensive update to the CTS Handbook. Nearly every wear chart

in the book was updated. The General Information section, the Management & Merchan-

dising section and the Management section of the four product types were also updated.

Some of the changes you will notice include:

• Cat Classic was added as a new section following Low Sprocket Machines.

• Nearly all wear charts were updated to some extent.

• The rounding was removed from all measurements for the Ultrasonic Wear Indicator.

• The carrier roller wear limits were increased for use with Heavy Duty, Rotating

Bushing and Extended Wear Life Track.

• Track roller wear charts for elevated sprocket machines now extend to the point at

which the wear surface meets the retainer bolt holes.

• Greater and Lesser Allowable wear columns were combined into one for large

excavators.

• The machine layout is now similar to the PSK, starting with small machines and

ascending to the large ones.

• The machine models are up-to-date.

• Pipelayer model numbers were added to the applicable section headers.

• The three excavator sections, the 300-Family, 200-Family and E-Family, can be more

easily located with the new, individual tabs.

• Undercarriage Codes for use with the CTS computer program were updated and

included in the front of each section and below each wear chart.

• The track seal replacement guidelines were updated.

Introduction
