Computer CTS Codes (cont’d)

Use the following undercarriage codes for computerized CTS:

Undercarriage

Model Code Description

215 SA C433 6.91 inch (175.5 mm) Pitch - 9S Roller rim

215 SA C434 6.91 inch (175.5 mm) Pitch - 9W Roller rim

217 C440 FB217 6.91 inch (175.5 mm) Pitch

219 C442 7.50 inch (190.0 mm) Pitch - 9W Roller rim

219 C443 7.50 inch (190.0 mm) Pitch - 8E Roller rim

221 C445 DL221 FB221 6.91 inch (175.5 mm) Pitch

225 C450 6.75 inch (171.5 mm) Pitch - 7K Roller rim

225 C451 6.75 inch (171.5 mm) Pitch - 9P Roller rim

225 C452 6.91 inch (175.5 mm) Pitch - 9S Roller rim

225 C453 6.91 inch (175.5 mm) Pitch - 9W Roller rim

225 C454 7.50 inch (190.0 mm) Pitch - 9W Roller rim

225 C455 7.50 inch (190.0 mm) Pitch - 8E Roller rim

225 SA C458 8.00 inch (203.2 mm) Pitch - 9G Roller rim

225 SA C463 8.00 inch (203.2 mm) Pitch - 8E Roller rim

227 C460 9G Roller rim

227 C462 8E Roller rim

229 C473 8.00 inch (203.2 mm) Pitch - 8E Roller rim

231 C472 8E Roller rim

235 C480 8.00 inch (203.2 mm) Pitch

235 C481 8.50 inch (215.9 mm) Pitch - 8S Links - 7T Roller

235 C482 8.50 inch (215.9 mm) Pitch - 8S Links - 9W Roller rim

235 C483 8.50 inch (215.9 mm) Pitch - 7T Links - 9W Roller rim

235 C484 8.50 inch (215.9 mm) Pitch - 7T Links - 8E Roller rim

235 C485 8.50 inch (215.9 mm) Pitch - 130-5333 & 8E Links -

D7H Roller

235 C486 8.50 inch (215.9 mm) Pitch - 130-5333 & 8E Links -

8E Roller rim

245 C490 9.00 inch (228.6 mm) Pitch

245 C491 10.25 inch (260.4 mm) Pitch - 9G Roller rim

245 C492 10.25 inch (260.4 mm) Pitch - 9W Roller rim

245 C493 10.25 inch (260.4 mm) Pitch - 9W Roller rim - D9N Idler

E070 C500 Small Diameter Track Roller

E070 C501 Large Diameter Track Roller

E110B C515 All

E120B C530 All

E180, EL180, E180 C560 All

E200, EL200, E200 C565 All

E140 C545 All

E240, EL240, E240 C590 All

E300, E300 C605 32 inch and 36 inch Shoe Widths

E300, E300 C606 24 inch Shoe Width

E300, EL300B, C607 32 inch and 36 inch Shoe Widths

E300B, EL300

E300, EL300B, C608 24 inch Shoe Width

E300B, EL300

E450 C625 All

E650 C640 All

492

INTRODUCTION

Excavators

10.Exc.(488-607) 7/14/03 7:32 AM Page 492
