Bushings for Sealed Track

External Wear

Grease Lubricated Track

Use only for 325 FM

Allowable Wear

Caliper Lesser Greater Ultrasonic

Inches (mm) % Worn % Worn Inches (mm)

2.86 (72.6) 0 0 0.53 (13.5)

2.85 (72.4) 5 4 0.52 (13.2)

2.84 (72.1) 10 8 0.51 (13.0)

2.83 (71.9) 15 12 0.50 (12.7)

2.82 (71.6) 20 16 0.49 (12.4)

2.81 (71.4) 25 20 0.48 (12.2)

2.80 (71.1) 30 24 0.47 (11.9)

2.79 (70.9) 35 28 0.46 (11.7)

2.78 (70.6) 40 32 0.45 (11.4)

2.77 (70.4) 45 36 0.44 (11.2)

2.76 (70.1) 50 40 0.43 (10.9)

2.75 (69.9) 55 44 0.42 (10.7)

2.74 (69.6) 60 46 0.41 (10.4)

2.73 (69.3) 65 48 0.40 (10.2)

2.72 (69.1) 70 50 0.39 (9.9)

2.71 (68.8) 72 52 0.38 (9.7)

2.70 (68.6) 74 54 0.37 (9.4)

2.69 (68.3) 76 56 0.36 (9.1)

2.68 (68.1) 78 58 0.35 (8.9)

2.67 (67.8) 80 60 0.34 (8.6)

2.66 (67.6) 82 62 0.33 (8.4)

2.65 (67.3) 84 64 0.32 (8.1)

2.64 (67.1) 86 66 0.31 (7.9)

2.63 (66.8) 88 68 0.30 (7.6)

2.62 (66.5) 90 70 0.29 (7.4)

2.61 (66.3) 92 72 0.28 (7.1)

2.60 (66.0) 94 74 0.27 (6.9)

2.59 (65.8) 96 76 0.26 (6.6)

2.58 (65.5) 98 78 0.25 (6.3)

2.57 (65.3) 100 80 0.24 (6.1)

2.56 (65.0) 102 82 0.23 (5.8)

2.55 (64.8) 104 84 0.22 (5.6)

2.54 (64.5) 106 86 0.21 (5.3)

2.53 (64.3) 108 88 0.20 (5.1)

2.52 (64.0) 110 90 0.19 (4.8)

2.51 (63.8) 112 92 0.18 (4.6)

2.50 (63.5) 114 94 0.17 (4.3)

2.49 (63.2) 116 96 0.16 (4.1)

2.48 (63.0) 118 98 0.15 (3.8)

2.47 (62.7) 120 100 0.14 (3.6)

2.46 (62.5) 102 0.13 (3.3)

2.45 (62.2) 104 0.12 (3.0)

2.44 (62.0) 106 0.11 (2.8)

2.43 (61.7) 108 0.10 (2.5)

2.42 (61.5) 110 0.09 (2.3)

2.41 (61.2) 112 0.08 (2.0)

2.40 (61.0) 114 0.07 (1.8)

2.39 (60.7) 116 0.06 (1.5)

2.38 (60.5) 118 0.05 (1.3)

2.37 (60.2) 120 0.04 (1.0)

Undercarriage Code: 592

533

325 FM — 8.00" (203.2 mm)

Excavators

10.Exc.(488-607) 7/14/03 7:32 AM Page 533
