Track Shoes

Chopper

Depth Gauge Ultrasonic

Inches (mm) % Worn Inches (mm)

3.15 (80.0) 0 3.75 (95.3)

3.05 (77.5) 5 3.65 (92.7)

2.95 (75.0) 10 3.55 (90.2)

2.85 (72.5) 15 3.45 (87.6)

2.75 (70.0) 20 3.35 (85.1)

2.65 (67.5) 24 3.25 (82.6)

2.55 (65.0) 28 3.15 (80.0)

2.45 (62.0) 32 3.05 (77.5)

2.35 (59.5) 36 2.95 (74.9)

2.25 (57.0) 40 2.85 (72.4)

2.15 (54.5) 44 2.75 (69.9)

2.05 (52.0) 48 2.65 (67.3)

1.95 (49.5) 52 2.55 (64.8)

1.85 (47.0) 56 2.45 (62.2)

1.75 (44.5) 60 2.35 (59.7)

1.65 (42.0) 64 2.25 (57.2)

1.55 (39.5) 68 2.15 (54.6)

1.45 (37.0) 72 2.05 (52.1)

1.35 (34.5) 76 1.95 (49.5)

1.25 (31.5) 80 1.85 (47.0)

1.15 (29.0) 84 1.75 (44.5)

1.05 (26.5) 88 1.65 (41.9)

0.95 (24.0) 92 1.55 (39.4)

0.85 (21.5) 96 1.45 (36.8)

0.75 (19.0) 100 1.35 (34.3)

0.65 (16.5) 104 1.25 (31.7)

0.55 (14.0) 108 1.15 (29.2)

0.45 (11.5) 112 1.05 (26.7)

0.35 (9.0) 116 0.95 (24.1)

0.25 (6.5) 120 0.85 (21.6)

NOTE: When measuring with the Ultrasonic Wear Indicator, measure in the center of the full length grouser.

Undercarriage Code: 164, 1641, 1642, 166, 169, 1698, 170, 1701, 173, 174, 1741

177

D7H, D7R, 572R — 8.50" (215.9 mm)

Elevated Sprocket Machines

03.Elev.(146-197) 7/11/03 3:44 PM Page 177
