Caterpillar Custom Track Service Handbook Page 299

Service Handbook

Page of 826

/ 826

Bushings for Sealed & Lubricated Track

Use with 6Y9261 & 62 Links and Small Stepped Bushings

Allowable Wear

Caliper Lesser Greater Ultrasonic Depth Gauge

Inches (mm) % Worn % Worn Inches (mm) Inches (mm)

2.23 (56.6) 0 0 0.43 (10.9) 2.80 (71.1)

2.22 (56.4) 6 5 0.42 (10.7) 2.79 (70.9)

2.21 (56.1) 12 10 0.41 (10.4) 2.78 (70.6)

2.20 (55.9) 18 15 0.40 (10.2) 2.77 (70.4)

2.19 (55.6) 24 20 0.39 (9.9) 2.76 (70.1)

2.18 (55.4) 30 25 0.38 (9.7) 2.75 (69.9)

2.17 (55.1) 36 30 0.37 (9.4) 2.74 (69.6)

2.16 (54.9) 42 35 0.36 (9.1) 2.73 (69.3)

2.15 (54.6) 48 40 0.35 (8.9) 2.72 (69.1)

2.14 (54.4) 54 45 0.34 (8.6) 2.71 (68.8)

2.13 (54.1) 60 50 0.33 (8.4) 2.70 (68.6)

2.12 (53.8) 66 55 0.32 (8.1) 2.69 (68.3)

2.11 (53.6) 70 60 0.31 (7.9) 2.68 (68.1)

2.10 (53.3) 73 62 0.30 (7.6) 2.67 (67.8)

2.09 (53.1) 76 64 0.29 (7.4) 2.66 (67.6)

2.08 (52.8) 79 66 0.28 (7.1) 2.65 (67.3)

2.07 (52.6) 82 68 0.27 (6.9) 2.64 (67.1)

2.06 (52.3) 85 70 0.26 (6.6) 2.63 (66.8)

2.05 (52.1) 88 72 0.25 (6.4) 2.62 (66.5)

2.04 (51.8) 91 74 0.24 (6.1) 2.61 (66.3)

2.03 (51.6) 94 76 0.23 (5.8) 2.60 (66.0)

2.02 (51.3) 97 78 0.22 (5.6) 2.59 (65.8)

2.01 (51.1) 100 80 0.21 (5.3) 2.58 (65.5)

2.00 (50.8) 103 82 0.20 (5.1) 2.57 (65.3)

1.99 (50.5) 106 84 0.19 (4.8) 2.56 (65.0)

1.98 (50.3) 109 86 0.18 (4.6) 2.55 (64.8)

1.97 (50.0) 112 88 0.17 (4.3) 2.54 (64.5)

1.96 (49.8) 115 90 0.16 (4.1) 2.53 (64.3)

1.95 (49.5) 118 92 0.15 (3.8) 2.52 (64.0)

1.94 (49.3) 121 94 0.14 (3.6) 2.51 (63.8)

1.93 (49.0) 96 0.13 (3.3) 2.50 (63.5)

1.92 (48.8) 98 0.12 (3.0) 2.49 (63.2)

1.91 (48.5) 100 0.11 (2.8) 2.48 (63.0)

1.90 (48.3) 102 0.10 (2.5) 2.47 (62.7)

1.89 (48.0) 104 0.09 (2.3) 2.46 (62.5)

1.88 (47.8) 106 0.08 (2.0) 2.45 (62.2)

1.87 (47.5) 108 0.07 (1.8) 2.44 (62.0)

1.86 (47.2) 110 0.06 (1.5) 2.43 (61.7)

1.85 (47.0) 112 0.05 (1.3) 2.42 (61.5)

1.84 (46.7) 114 0.04 (1.0) 2.41 (61.2)

1.83 (46.5) 116 0.03 (0.8) 2.40 (61.0)

1.82 (46.2) 118 0.02 (0.5) 2.39 (60.7)

1.81 (46.0) 120 0.01 (0.3) 2.38 (60.5)

Undercarriage Code: 134, 135, 1353, 307, 3071

298

D5G, D5C, 939 — 6.75" (171.5 mm)

Low Sprocket Machines

05.Low(246-325) 7/11/03 3:52 PM Page 298
