Caterpillar Custom Track Service Handbook Page 35

Service Handbook

Page of 826

/ 826

Former Link Service Limits

These former links do not appear on the wear chart pages. But, by using this procedure

and chart, you can calculate the percent worn measurement.

STEP 1 STEP 2

New Link Height - Worn Link Height = Amount Worn Amount Worn

Allowable Wear x 100 = Percent Worn

Track Link New Link Allowable

Model Pitch Part Number Height Wear Service

D2 6.12" 5B3129 & 30 3.00" .25" 2.75"

(155.4 mm) (76.2 mm) (6.4 mm) (69.9 mm)

D3 6.125" 6S3143 & 44 3.18" .26" 2.92"

155.3 mm (81 mm) (7 mm) (74 mm)

D4 6.75" 5K9423 & 24 3.66" .25" 3.41"

(171.5 mm) (93.0 mm) (6.4 mm) (86.6 mm)

6.75" 5K9457 & 58 3.66" .25" 3.41"

(171.5 mm) (93.0 mm) (6.4 mm) (86.6 mm)

6.75" 4K6647 & 48 3.66" .25" 3.41"

(171.5 mm) (93.0 mm) (6.4 mm) (86.6 mm)

6.75" 4K7039 & 40 3.66" .25" 3.41"

(171.5 mm) (93.0 mm) (6.4 mm) (86.6 mm)

6.75" 6B4645 & 46 3.53" .25" 3.28"

(171.5 mm) (87.7 mm) (6.4 mm) (83.3 mm)

D5 6.91" 5S683 & 84 4.06" .37" 3.69"

(175.5 mm) (103.1 mm) (9.4 mm) (93.7 mm)

D6 8.00" 9M5627 & 28 4.50" .30" 4.20"

(203.2 mm) (114.3 mm) (7.6 mm) (106.7 mm)

6.75" 2S5959 & 60 4.00" .34" 3.66"

(171.5 mm) (101.5 mm) (8.6 mm) (93.0 mm)

6.75" 7M8863 & 64 3.91" .30" 3.61"

(171.5 mm) (99.3 mm) (7.6 mm) (91.7 mm)

6.75" 1M1431 & 32 3.91" .30" 3.61"

(171.5 mm) (99.3 mm) (7.6 mm) (91.7 mm)

6.75" 5H8679 & 80 3.78" .30" 3.48"

(171.5 mm) (96.0 mm) (7.6 mm) (88.4 mm)

D7 8.50" 2S1749 & 50 4.75" .35" 4.40"

(215.9 mm) (120.7 mm) (8.9 mm) (111.8 mm)

8.50" 1M9001 & 02 4.75" .35" 4.40"

(215.9 mm) (120.7 mm) (8.9 mm) (111.8 mm)

8.00" 1S6433 & 34 4.63" .38" 4.25"

(203.2 mm) (117.6 mm) (9.7 mm) (108.0 mm)

8.00" 7M8085 & 86 4.50" .38" 4.12"

(203.2 mm) (114.3 mm) (9.7 mm) (104.6 mm)

LINKS
