Non-Controllable Variables

There are a number of variables that affect

rates and patterns of wear which cannot be

controlled. These should be understood so

you can explain their effects.

Non-controllable variables include soil and

underfoot conditions (abrasion, impact,

packing, etc.), application conditions (what

the machine is doing) and terrain conditions.

Soil & Underfoot Conditions

Generally, soil and underfoot conditions

cannot be controlled. They include the

abrading, impacting, packing and even

corrosive and temperature effects of the

immediate environment.

Abrasiveness

Abrasiveness of underfoot conditions is

the most difficult to accurately measure

except by its effect. We use these descrip-

tions to identify relative abrasiveness in

terms of high, moderate and low:

Abrasiveness Ratings Descriptions

High — Saturated wet soils containing a

majority of hard, angular or sharp sand

particles.

Moderate — Slightly or intermittently

damp soils containing low proportion of

hard, angular or sharp particles.

Low — Dry soils or rock containing a

very low proportion of hard, angular sharp

sand or rock chip particles.

The amount of moisture plays a big role in

defining abrasiveness. For example, dry,

pure quartz sand may be only 1/10 as

abrasive as saturated wet, pure quartz sand

slurry and only 1/2 as abrasive as it is in a

damp condition. This is because moisture

affects the rate that particles are carried to

and stuck to the metal surface being worn.

Some abrasive combinations tend to attack

the bushing, others the grousers and still

others the links and rollers. These differences

are difficult to quantify except by actual

experience, but you should be aware of the

possibility.

Usually, the link is the best component to

use for comparing overall relative abrasive

effects because it is least subjected to other

variables at the same time. This is why we

use the link as the “base” or “barometer”

component when comparing wear lives to

the service limit of different components

in different abrasive conditions.

Impact

Impact is not affected by other variables

such as moisture or hardness of the parti-

cles that make up the soil. It can be

defined as high, moderate or low. Impact

is determined by weight of the machine

and speed is defined under APPLICA-

TION CONDITIONS later in this sub-

section.

Impact Ratings Description

High — Non-penetratable hard surfaces

with constant exposure to 6" (15 cm) or

higher “bumps.”

Moderate — Partially penetratable surfaces

with constant exposure to smaller bumps.

Low — Completely penetratable surfaces

(which provide full shoe plate support)

with low exposure to any height “bumps”.

The most measurable effect of impact is

on structural problems such as bending,

cracking, breaking, chipping, spalling,

roll-over and hardware and pin and

bushing retention. However, the degree of

impact when combined with abrasiveness

may affect component wear rates and

wear life by a factor of two or more. For

example, a D6 dozing at a given speed on

completely compacted or frozen sandy soil

with a deeply furrowed surface (high

impact) may get only one-half the wear

life on links as it would if the same soil

were loose, soft and smooth (low impact).

Generally, wear life of larger machines are

less affected by variations in impact than

smaller machines.

General Information

NON-CONTROLLABLE VARIABLES — UNDERFOOT CONDITIONS
