Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 82

Systems Operation Troubleshooting Testing and Adjusting
82 KENR8601
Troubleshooting Section
Table 17
Selection of AC Voltage Range
GSC+P
P020
Setpoint
External
Potential
Trans-
former
Input
Voltages
for AC
Trans-
former
Box
(ATB+)
GSC+P
Internal
Multiplier
Jumper
700 None 0 - 700
5
Yes
150 None 0 - 150 1 None
300 2:1 0 - 150 2 None
500 3.33:1 0 - 150 3.33 None
600 4:1 0 - 150 4 None
750 5:1 0 - 150
5
None
3000 20:1 0 - 150 20 None
4500 30:1 0 - 150 30 None
5250 35:1 0 - 150 35 None
9000 60:1 0 - 150 60 None
15000 100:1 0 - 150 100 None
18000 120:1 0 - 150 120 None
30000 200:1 0 - 150 200 None
Note: Fo r r ela ted information, Testing An d A dju sting ,
“AC Voltage Range - Adjust”.
The P020 setpoint determines the proper AC voltage
range and the internal multipliers that are used by
the GSC+P for calculating AC voltage. If the external
potential tran s f ormers a re present, the GSC+P uses
the internal multipliers to compensate for the ratio of
turns of the external potential transformers. This must
take place in order to ensure accurate calculations by
the GSC+P for AC vo ltage .
A jumper block is located in the relay module. The
jumper block connects a circuit which will divide
the AC voltage by five. The circuit reduces the AC
voltage to an acceptable level for the GSC+P when
P020 is 700. When setpoint P020 is 700, a multiplier
of five is needed to compensate for the presence
of the circuit even though no external potential
transformer is present.
Note: The jumper block should NOT be installed
when P020 is NOT programmed to a value of 700.
This will prevent voltage readings that are calculated
incorrectly by the GSC+P. The other values (150
through 30000) are used with an external potential
transformer. These values result in input voltages
from 0 to 150 ACV at the AC Transformer Box +
(ATB+). No further reduction of the input voltage is
required.
When the engine-generator, or any source to
which the engine-generator is synchronized to, is
operating, voltages up to 600V are present in the
control panel.
Do not short these terminal with line voltage to
ground with any part of the body or any conduc-
tive material. Loss of life or injury could result
from electrical shock or injury from molten met-
al.
Tes t Step 1. CHECK THE DISPL AY OF
THE GSC+P FOR VOLTAGE READINGS
A. Start the genset.
B. Check the voltage readings on the display of the
GSC+P.
Expected Result:
The voltage readin gs on the GSC+ P should be
accurate .
Results:
•
OK – The voltage readings on the GSC+P are
accurate. Proceed to Test Step 2.
•
NOT OK – The voltage readings on the GSC+P
are inaccurate. Proceed to Test Step 4.
Tes t Step 2. CHECK THE DISPL AY OF
THE GSC+P FOR CURRENT READINGS
A. Check the current readings on the display of the
GSC+P.
Expected Result:
The current readings on the GSC+P should be
accurate .
Results:
•
OK – The current readings on the GSC+P are
accurate. Proceed to Test Step 3.
•
NOT O K – The current readings on the GSC+P
are inaccurate. Proceed to Test Step 8.
Tes t Step 3. CHECK THE DISPLAY OF T HE
GSC+P FOR POWER CON SU MP TION
A. Check the power consumption on the display of
the GSC+P.
