Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 25

Systems Operation Troubleshooting Testing and Adjusting
KENR8601 25
Systems Operation Section
i02898014
Paralleling Mode
SMCS Code: 4490
g01445132
Illustration 33
Parallel Control Switch
(1) MANUAL (
Permissive) Position
(2) OFF Posi
tion
(3) AUTO Pos
ition
The GSC+P is in P aralle l Mode whe n ever the Parallel
Control Swi
tch (PCS) is in the AUTO position, or the
Permissive position. There are several p aralleling
functions within Parallel Mode. These functions are
determined
by the following items: PCS and Engine
Control Switch (ECS).
g00688669
Illustration 34
Note: The EMCP II+P is not designed f or paralleling
with a UTILITY in a standard installation. The EMCP
II+P WILL support paralleling of multiple generators.
The EMC P II+P can be reconfigured to operate in
parallel with a utility, bu t must be modified to operate
in droop mode. Additional components must be
added in order to perform proper load control when
paralleling with a utility. T he se sub jects are beyond
the scope of th is manual. Consu lt yo ur Caterpillar
Dealer for more information.
Note: The GSC+P is not intended for use with DELTA
WIRED G EN ERATORS. If setpoint P032 is set to 1
(delta generators), the synchroscope will flash as
shown in illustra tion 34. An “AL 1 7” diagn os tic code
will appear when the “Alarm Codes” key is pressed.
