Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 189

Systems Operation Troubleshooting Testing and Adjusting
KENR8601 189
Testing and Adjusting Section
(Table 28, contd)
Service Table - R
ecord Of Setpoint Values
Generator Description : Site, Serial No., EMCP II+ Part No., etc..
OP5-1 Setpoints
(1)
- Protective Relaying Pro g ramming
Setpoint Specified Value
Actual Value
(1)
Name
Range Of Value
Factory
Default
P118
Overfrequency
Shutdown Time Delay
0 to 120 seconds
(2)
in increments
of 1
10
seconds
P119
Underfrequency Alarm
Enable
0 - disabled
1 - enabled
1
MUI Engines: 30 to 50, for 50 Hz
Gen
45 Hz
PEEC and EUI Engines: 30 to 50,
for 50 Hz G en
47 Hz
MUI Engines: 36 to 60, for 60 Hz
Gen
54 Hz
PEEC and EUI E
ngines: 36 to 60,
for 60 Hz G en
57 Hz
MUI Engines: 240 to 400, for 400
Hz Gen
360 Hz
P120
Underfrequency Alarm
Threshold
PEEC and EUI Engines: 240 to
400, for 400 Hz Gen
378 Hz
P121
Underfrequency Alarm
Time Delay
0 to 120 seco
nds
(2)
in increments
of 1
10
seconds
P122
Underfrequency
Shutdown En
able
0 - disabled
1 - enabled
1
P123
Underfrequency
Shutdown Threshold
30 to 50, for 50 Hz Gen
36 to 60, for 60 Hz Gen
240 to 400, for 400 Hz Gen
45 Hz
54 Hz
360 Hz
P124
Underfrequency
Shutdown Time Delay
0 to 120 seconds
(2)
in increments
of 1
15
seconds
P125 Reverse Pow
er
Shutdown E nable
0 - disabled
1 - enabled
1
P126 Reverse Power
Shutdown Th
reshold
0 to 20% of nameplate power in
increments of 1%
15%
P127 Reverse Power
Shutdown Time Delay
0to30seconds
(2)
in increments
of 1
10
seconds
P128
Overcurre
nt Alarm
Enable
0 - disabled
1 - enabled
1
P129
Phase Overcurrent
Alarm Threshold
100 to 160% of na meplate current
in increments of 5%
105%
MUI
Engines:
20
seconds
P130
Phase Overcurrent
Alarm Time Delay
0 to 250 seconds
(2)
in increments
of 1
PEEC
and EUI
Engines:
0
seconds
(continued)
Previous page
Next page
