Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 41

Systems Operation Troubleshooting Testing and Adjusting
KENR8601 41
Systems Operation Section
2. Press “SCROLL UP” key two times. “OP5-1” is
showing on the lower display.
3. Press “SELECT” key once. “P101” is showing.
“P101” is followed by the value of the setpoint.
4. Press the “SCROLL UP” key or the “SCROLL
DOWN” key. The next setpoint is showing with the
setpoint value. Repeat this step until the desired
setpoint is showing.
5. Press “SELECT” key. The value of the setpoint
is fl ashing.
6. Press the “SCROLL UP” or the “SCROLL DOWN”
key in order to adjust the value of the setpoint.
Note: In order to rapidly scroll through a large range
of values, press and hold the appropriate “SCROLL”
key.
7. Press “ENTER” key. The value of the setpoint
stops flashing. Repeat steps 4 , 5, 6 and 7 until all
the desired setpoints are a djusted.
8. Press “EXIT” key. “OP 1” is showing on the lower
display.
9. Press “EXIT” key. The display returns to normal
mode.
Table 7
OP5-1 Setpoints
(1)
- Protective Relaying Pro g ramming
Setpoint
Name Descripti
on
Range Of Value
Factory
Default
P101
Overvoltage Alarm
Enable
The GSC+P enables or disables the
generator overvoltage alarm function.
0 - disabled
1 - enabled
1
P102
Overvoltage Alarm
Threshold
Voltage the GSC+P uses to issue an
overvoltage alarm.
100 to 125% of nameplate
voltageinincrementsof1%
105%
P103
Overvoltage Alarm
Time Delay
Amount of time the GSC+P waits
before issuing an overvoltage alarm.
0to120se
conds
(2)
in increments
of 1
10
seconds
P104
Overvoltage
Shutdow
n Enabled
The GSC+P enables or disables
the gene
rator ove rvoltage shutdo wn
function.
0 - disabled
1 - enabled
1
P105
Overvoltage
Shutdown Threshold
Voltage the GSC+P uses to issue an
overvoltage shutdown.
100 to 125% of nameplate
voltageinincrementsof1%
110%
P106
Overvoltage
Shutdown Time Delay
Amount of time the GSC+P waits
before inssuing an overvoltage
shutdow
n.
0to120seconds
(2)
in increments
of 1
10
seconds
P107 Undervoltage Alarm
Enable
The GSC+P enables or disables the
generator undervoltage alarm function.
0 - disabled
1 - enabled
1
P108 Undervoltage Alarm
Threshold
Voltag
e the GSC+P uses to issue an
undervoltage alar m.
60 to 10
0% of nameplate voltage
in increments of 1%
90%
(conti
nued)
