Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 185

Systems Operation Troubleshooting Testing and Adjusting
KENR8601 185
Testing and Adjusting Section
i02906092
Service Record
SMCS Code: 4490
Table 26
Service Table - Record Of Setpoint Values
Generator Description : Site, Serial No., EMCP II+ Part Number., etc..
Engine /Generator Programmin g OP5-0
Setpoint Specified Value
Actual Value
(1)
Setpoint Description
Possible Values
Default Value
P001
Fuel Solenoid Type 0 = ETR, 1 = ETS
0
P002
Units Shown
0=Eng,1=metric 0
P003
Shutdown Override For
Engine Fault
0 = shutdown,
1=alarm
0
P004
Shutdown Ena
ble For
Sensor Fault
0 = alarm,
1 = shutdown
0
P005
Coolant Loss Sensor
Installed
0=w/osensor,
1 = w/sensor
0
P006
Shutdown Override For
Coolant Loss Fault
0 = shutdown,
1=alarm
0
P007
System Voltage
24 volts or 32
volts
24
P008
This Setpoint Is Not Used.
NA NA
P009
Number Of Ring Gear Teeth
95 to 350 teeth
136 teeth for
MUI and PEEC
engines. 183
teeth for EUI
engines.
P010
Engine Overspeed
500to4330rpm 2120rpm
P011
Crank Terminate Speed
100to1000rpm 400rpm
P012
Oil Step Sp
eed
400to1800rpm 1350rpm
P013
Low Oil Pressure Shutdown
At Rated Speed
34 to 420 kPa
(5 to 61 psi)
205 kPa (30 psi)
P014
Low Oil Pre
ssure Shutdown
At Idle Speed
20 to 336 kPa
(3 to 49 psi)
70 kPa (10 p
si)
P015 High Water Temperature
Shutdown
85 to 123°C
(185 to 253°F)
107°C (225°F)
P016 Low Water Temperature
Alarm
0 to 36°C (32 to 97°F) 21°C (70°F)
P017
Total Cyc
le Crank Time
5 to 360 se conds 90 seconds
P018
Cycle Crank Time
5 to 300 se conds 10 seconds
P019
Cooldown Time
0 to 30 minutes 5 minutes
P020
AC Voltage
150V to 3 0
.0 kV
700V
P021
AC Current Fu ll Scale
75A to 4000A 600A
P022
GSC+ Engine Number
01 to 08 01
P023 Engine Type 0 = MUI
1=GAS
2=EUI
(continued)
