Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 51

Systems Operation Troubleshooting Testing and Adjusting
KENR8601 51
Systems Operation Section
i02898745
Voltmeter/Ammeter
Programming O P8
SMCS Code: 4490
Table 10
OP8 S etpoints
(1)
- Voltmeter Ammeter Programming
Setpoint
Name Description
Range Of Value
Factory
Default
AC01 Phase A (VA) Voltage
Calibration
Calibration value used by the GSC+P to compensate for
the characteristics of the phase A voltage tra nsformer
within the ATB+.
0to255in
increments of
1
0
AC02 Phase B (VB) Voltage
Calibration
Calibration value used by the GSC+P to compensate for
the characteristics of the phase B voltage tra nsformer
within the AT
B+.
0to255in
increments of
1
0
AC03 Phase C (VC) Voltage
Calibration
Calibration value used by the GSC+P to compensate for
the characteristi cs of the phase C voltage transforme r
within the ATB+.
0to255in
increments of
1
0
AC04 Phase A (IA) Current
Calibration
Calibration value used by the GSC+P to compensate for
the charac teristics of the phase A current transformer
within the A
TB+.
0to255in
increments of
1
0
AC05 Phase B (IB) Current
Calibration
Calibration value used by the GSC+P to compensate for
the charac teristics of the phase B current transformer
within the ATB+.
0to255in
increments of
1
0
AC06 Phase C (IC) Current
Calibration
Calibration value used by the GSC+P to compensate for
the characteristics of the phase C current transformer
within the
ATB+.
0to255in
increments of
1
0
AC07
(2)
Phase A (VA) Voltage
Calibration of BTB+
Calibration value used by the GSC+P to compensate for
the characteristics of the phase A voltage tra nsformer
within the B TB+.
0to255in
increments of
one.
0
(1)
The setpoints are programmed at the factory to the calibration value listed on the bar code sticker of the ATB+.
(2)
Setpoint is available on GSC+P only.
OP8 is the option for programming the calibration
value of the voltmeter and ammeter. When the
GSC+P or the AC transformer box + (ATB+) has
been replaced, the calibration values that are written
on the ATB+ bar code sticker, must be programmed
into the GSC+P in order to ensure accurate voltage
values and current values.
The GSC+P monitors six transformers in the ATB+
for information about the voltage and c urrent. Each
transformer has individual characteristics that affect
the voltage and current measurements that are taken
by the GSC+P. A calibration value is measured and
the value is assigned at the factory. The calibration
value is recorded on the bar code sticker that is
located on the lower left hand side of the ATB+.
When the generator set is assembled at the factory,
the calibration values on the bar code sticker are
programmed into the GSC+P. The transformers
calibration value is 0 to 255. The transformers
calibration v alu e uses increments of 1.
Procedure For Voltmeter/Ammeter
Programming
Note: Service Mode cannot be entered when the
Engine Control Switch (ECS) is in the AUTO position.
Note: Any active shutdo w n fault must be made
inactive in order to access Service Mode. To
temporarily change a shutdown fault from an active
shutdown to an inactive shutdown fault, turn the
ECS to the OFF/RESET position. To permanently
change a shutdown fault from an active shutdown
fault to an inactive shutdown fault, the fault must not
be occurring. Also, the ECS must be turned to the
OFF/RESET position. If the jumper from terminal 6
to terminal 9 is not installed on the ECS, the G SC+ P
does not power up in OFF/RESET and any active
shutdown fault must be corrected before entering
service m ode.
