Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 16

Systems Operation Troubleshooting Testing and Adjusting
16 KENR8601
Systems Operation Section
Table 1
Load Specifications For GSC+P Relay Module
Relay Module Terminal
Number
Rating For
Resistive
Loads
Rating For
Inductive
Loads
RM13,14 - K1 - EGR
N/O
0.45A at
24DCV
none
(1)
RM15 - K7 - FCR N/O
RM16 - K3 - CTR N/O
RM17 - K3 - CTR N/
C
RM18 - K4 - SMR N/O
RM21 - K4 - SMR N/C
RM19 - K6 - ASR N/
O
RM20 - K6 - ASR N/C
RM22 - K2 - GFR N/O
RM24 - K5 - RR N/O
10A at
24DCV
10A at
24DCV
RM36,23 - K 5 - RR N/C
RM37,26 - K8 - PSR
N/C
RM38,25 - K8 - PSR
N/O
10A at
24DCV
5A at 24DCV
(1)
Do NOT connect inductive loads to th ese terminals.
The relays and the functions are listed below.
K1 – Electronic Governor Relay (EGR)
For the C32 package, this contact sends a run
commandtotheECMontheenginetobeginthe
cranking sequence.
•
When the relay is active the normally open contacts
close.
•
The relay has no normally closed contacts.
K2 – Ge n erator Fault Relay (G F R)
The G SC+P uses the generator fault relay (GFR)
to activate the shunt trip coil of the optional circuit
breaker during a shutdown fault. The circuit breaker
is located in the generator housing.
•
When the relay is active the normally open contacts
close. This trips the optional circuit breaker when a
shutdown fault occurs.
•
The relay has no normally closed contacts.
K3 – Crank Termination Relay (CTR)
The CTR is used to indicate that the engine is
beginning to run without cranking. The GSC+P
activates the CTR when the engine speed is
greater than the crank terminate setpoint (400 RPM,
setpoint P011) and the starting motor relay has been
deactivated. The CTR deactivates when the engine
RPM reaches 0.
•
When the relay is active the normally open contacts
close.
•
When the relay is inactive the normally closed
contacts close.
K4 – Sta rt ing Moto r Relay (SMR)
•
When the relay is active the normally open contacts
close. This output is not used on the C32 package
generator set.
•
When the relay is inactive the normally closed
contacts close.
•
This relay is not used.
K5 – Run Relay (RR)
•
When the relay is active the normally open contacts
close. This provides power to the Run Relay (RR),
AC Control Power Relay (AC-CR2). The K5 relay
also sends the run command to the ADEM 3
controller on the engine.
•
When the relay is inactive the normally closed
contacts close. This contacts are for customer use.
K6 – Air Shutoff R elay (ASR)
•
When the relay is active the normally open contacts
close.
•
When the relay is inactive the normally closed
contacts close.
•
This relay is not used.
K7 – Fuel Co ntrol R elay (FCR)
•
When the relay is active the normally open contacts
close.
•
The relay has no normally closed contacts.
•
This relay is not used.
K8 – Programmable Spare Relay (PSR)
On non-paralleling panels, this relay is for customer
use. It is programmable to activate for a variety of
conditions. On paralleling panels, this relay is used by
the EMCP II+P and is not available for customer use.
For more information, refer to Systems Operation,
“Service Mode”.
•
When the relay is active, the normally open
contacts close.
•
When the relay is inactive, the normally closed
contacts close.
