Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 42

Systems Operation Troubleshooting Testing and Adjusting
42 KENR8601
Systems Operation Section
(Table 7, contd)
OP5-1 Setpoints
(1)
- Protective Relaying Pro g ramming
Setpoint
Name Description
Range Of Value
Factory
Default
P109 Undervoltage A
larm
Time Delay
Amount of time the GSC+P waits
before inssuing an undervoltage alarm.
0to120seconds
(2)
in increments
of 1
10
seconds
P110 Undervoltage
Shutdown Enable
The GSC+P enables or disables the
generator unde
rvoltageshutdown
function.
0 - disabled
1 - enabled
1
P111 Undervoltage
Shutdown Thre
shold
Voltage the GSC+P uses to issue an
undervoltage shutdown.
60 to 100% of nameplate voltage
in increments of 1%
85%
P112 Undervoltage
Shutdown Time Delay
Amount of time the GSC+P waits
before issuing an undervoltage
shutdown.
0to120seconds
(2)
in increments
of 1
15
seconds
P113
Overfrequency Alarm
Enable
The GSC+P enables or disables
the generator overfrequency alarm
function.
0 - disabled
1 - enabled
1
P114
Overfrequency Alarm
Threshold
Frequency t hat t he GSC+P uses to
issue an overfrequency alarm.
50 to 60, for 50 Hz Gen
60 to 70 , for 60 Hz Gen
400 to 480, fo
r400HzGen
53 Hz
63 Hz
422 Hz
P115
Overfrequency Alarm
Time Delay
Amount of time the GSC+P waits
before issuing an overfrequency alarm.
0to120seconds
(2)
in increments
of 1
10
seconds
P116
Overfrequen
cy
Shutdown Enable
The GSC+P ena
bles or disables the
generator overfrequency shutdown
function.
0 - disabled
1 - enabled
1
50 to 60, for 50 Hz Gen
55Hz
PEEC and EUI Engines: 60 to
70, for 60Hz Gen
66 Hz
MUIEngines:60to70,for60Hz
Gen
63 Hz
PEEC and EUI Engines: 400 to
480, for 40
0HzGen
440 Hz
P117
Overfrequency
Shutdown Threshold
Frequency the GSC+P uses to issue
an overfrequency shutdown.
MUI Engines: 400 to 480, for 400
Hz Gen
422 Hz
P118
Overfrequ
ency
Shutdown Time Delay
Amount of t
ime the GSC+P waits
before issuing an overfrequency
shutdown.
0to120seconds
(2)
in increments
of 1
10
seconds
P119
Underfrequency Alarm
Enable
The GSC+P enables or disables
the generator un derfrequency alarm
function.
0-disable
d
1 - enabled
1
(continued)
