Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 32

Systems Operation Troubleshooting Testing and Adjusting
32 KENR8601
Systems Operation Section
Service Mode has options that can be selected.
Service personnel use the options to obtain
information about the generator set, and the operator
can program functions of the generato r set.
Table 5
OP1, Fault log v
iewing
OP2-0, Engine/Generator setpoint v iewing
OP2-1, Protective relaying setpoint viewing
OP2-2, AC factory calibration setpoint viewing
OP2-3, Synchronization setpoints
(1)
OP3, Password entry
OP4, Fault log
clearing
OP5-0, Engine/Generator programming
OP5-1, Protective relaying programming
OP5-2, For factory use, not accessible by the user.
OP5-3, Synchroniza tion setpoint programming
(1)
OP6, Spare Input/Output programming
OP7, Hour met
er programmi ng
OP8, Voltmeter/Ammeter programming
OP9, Engine setpoint verification
OP10,ACoffsetadjustment
OP11, S ynchronization setpoint tuning
(1)
(1)
For use in para lleling applications only.
ThekeypadandthedisplayoftheGSC+Pareused
for activating Service Mode and selecting the desired
option. In S
ervice Mode, the keys on the keypad have
different functions, and the keys on the keypad have
different names. The preceding illustratio n shows
the name of
each key in Service Mode. Also, there
is a film (label) on the door of the control panel that
identifies each key. The service functions of the keys
are listed
below.
Scroll Right Key – This key is used to view
informati
on and scroll information. When you are
entering the password, this key represents the
number 1.
Scroll Up Key – This key is used to scroll up
information or this key is used to increase the value
of inform
ation. When you are entering the password
this key represe nts the number 2.
Scroll Do
wn Key – Thiskeyisusedtoscrolldown
through information or this key is used to decrease
the value of information. When you are entering the
passwor
d, this key represents the number 3.
Note: The appropriate “Scroll” Key should be held
down in order to rapidly scroll through a large range
of information.
Select Key – To view an option, use the Select Key.
To change an option, use the Select Key. To start the
scrolling of in fo rm a tio n , use the Se lect Key.
Enter Key – This key is used to enter information
that has been changed into the memory of the
GSC+P.
Exit Key – This key is u sed to exit Service Mode.
The display now returns to Normal Mode. The “SERV”
indicator on the upper display is NOT SHOWING
when the GSC+P is NOT in Service Mode.
Service Mode Key – Thiskeyisusedtoenter
Service Mode. The “SERV” indicator on the upper
display FLASHES when the GSC+ P is in Service
Mode. T he “SERV” indicator on the upper display
FLASHES when the keypad performs functions in
the Service Mo de.
Procedure To Enter Service M ode
Note: Any active shutdo w n fault must be made
inactive in order to access Service Mode. A
FLASHING shutdown indicator means that a
shutdown fault exis ts. To tempor arily change a
shutdown fault from an active shutdown fault to an
inactive shutdown fault, turn the Engine Control
Switch (ECS) to the OFF/RESET position. To
permanently change a shutdown fault from an active
shutdown fault to an inactiv e shutdow n fault, the
fault must not be occurring. Also, the ECS must be
turned to the OFF/R ESET position. If the jumper from
terminal 6 to terminal 9 is not installed on the ECS,
then the G SC+P will not power up in OFF/RESET
and any active shutdown fault must be corrected
before entering Service Mode.
Note: Service Mode cannot be entered when the
ECS is in the AUTO position.
1. Press the “SERVICE MODE” key on the keypad
of the GSC+P. The “SERV” indicator on the upper
display FLASHES whenever the GSC+P is in
Service Mode.
2. The desired option (OP1 through OP11) can now
be selected. Each option is described in the topics
that follow.
3. To return to Normal Mode, pre ss the “EXI T” key
a few times until the “SERV” indicator is not
showing.
Note: To enter options OP4 through OP8 of the
Service Mode, the engine must be shut down. Turn
the ECS to the STOP positio n.
