Caterpillar Engine Tools Cat Overhaul 3512 Page 54

Operation and Maintenance Manual
2588079
3-54
Engine Tools
Crankshaft, Main Bearings and Flywheel
Crankshaft Seal and Wear Sleeve Installation Tools (Silicone and Hydrodynamic) (Continued)
Model: 1100, 3100, 3200, 3300, 3400
Warranty: Six Months
CURRENT ENGINES
Item Location Part Number Description Qty.
3500 Engines - Hydrodynamic Seals - SMHS8508 (Continued)
5 Rear 2J-3505 Full Nut 4
6 Front and
Rear
2N-5006 Bolt 2
-- Front and
Rear
1U-7325 Distorter Adapter --
-- Front and
Rear
6V-3143 Distorter Adapter --
-- Rear 5P-7409 SleeveDistorter --
C27/C32 Engines - Hydrodynamic Seals - SMHS8508
1 Front and
Rear
5P-1733 Locator --
1 Rear 249-2937 Locator --
2 Front 6V-6142 Installer --
2 Rear 6V-6143 Installer --
5 Front and
Rear
9S-8858 Nut Assembly --
-- Front and
Rear
5P-7312 Distorter --
-- Front and
Rear
5P-7314 Distorter Ring --
C175 Engines - Hydrodynamic Seals - SMHS8508
1 Front and
Rear
250-4586 Locator --
2 Front and
Rear
250-4587 Installer --
3, 4 Front and
Rear
323-4712 Other Part --
5 Front and
Rear
9S-8858 Nut Assembly --
6 Front and
Rear
322-2078 Bolt --
-- Front and
Rear
1U-7325 Distorter Adapter --
-- Rear 5P-7409 SleeveDistorter --
D343 (5.4 in) 6 Cylinder Engines - Silicon Seals - SMHS7100
1 Front 9S-8876 Locator --
1 Rear 9S-8870 Locator --
2 Front 5P-7295 Installer --
2 Rear 5P-7294 Installer --
5 Front and
Rear
9S-8858 Nut Assembly --
6 Front 9S-8889 Bolt 2
6 Rear 2P-2346 Bolt 3
-- Front 5P-7316 Distorter Ring --
CURRENT ENGINES
Item Location Part Number Description Qty.
D343 (5.4 in) 6 Cylinder Engines - Silicon Seals - SMHS7100
(Continued)
-- Front and
Rear
5P-7312 Distorter --
D348 (5.4 in) 60 degree Vee Engines - Silicon Seals -
SMHS7100
1 Front 5P-7302 Locator --
1 Rear 9S-8874 Locator --
2 Front 5P-7297 Installer
4
--
5 Front and
Rear
9S-8858 Nut Assembly --
6 Front 9S-8889 Bolt 2
6 Front and
Rear
9S-8893 Bolt 3
-- Front 5P-7316 Distorter Ring --
-- Front and
Rear
5P-7312 Distorter --
(5.4 in) 60 degree Vee Engines - Hydrodynamic Seals -
SMHS8508
1 Front 5P-7302 Locator --
1 Rear 9S-8874 Locator --
2 Front 4C-5822 Installer --
2 Rear 9U-5114 Seal and Wear
SleeveInstaller
--
5 Front and
Rear
9S-8858 Nut Assembly --
6 Front 9S-8889 Bolt 2
6 Front and
Rear
9S-8893 Bolt 3
-- Front 5P-7316 Distorter Ring --
-- Front 7C-7473 Seal --
-- Front and
Rear
5P-7312 Distorter --
-- Rear 7C-7474 Seal --
D379, D398, D399, G379, G398 and G399 Engines - Hydrody-
namic Seals - SMHS8301
1 -- 6V-7829 Locator --
2 -- 6V-7831 Installer --
3, 4 -- 6V-7833 Other Part --
3, 4 -- 6V-7799 Other Part --
5 Front and
Rear
9S-8858 Nut Assembly --
6 -- 4B-5271 Bolt 6
6 -- 3B-1915 Bolt 6
6 -- 6V-9442 Bolt 2
(Continued)
