Caterpillar Engine Tools Cat Overhaul 3512 Page 187

Operation and Maintenance Manual
2645154
2645162
3-187
Engine Tools
Engine Test Tools
Skidders
Model Serial Number Adapter
518 50S, 55U, 94U, 95U FT0719-2
528 51S, 78W FT0719-2
814 90P, 14R FT0719-2
815 91P, 15R FT0719-2
816 57U FT0719-2
824 29C¹ FT0718-1
824B 36H1-313¹ FT0718-1
824B 36H314 FT0775-2
826B 58U FT0775-2
834 43E1-313¹ FT0718-1
834 43E314 FT0775-2
835 44N FT0775-2
¹UseFT0775Adapteronenginesequippedwithdiscontinued4S-9643or9S-7536(notserviced)CrankshaftReplacementGear
Group
Wheel Loaders
Model Serial Number Adapter
910 80U FT0730-4
920 62K, 41J, 75J FT0719-2
922 63A FT0716
922 59A FT0717-1
922B 94A, 74J, 88J FT0719-2
930 41K, 79J FT0719-2
944 58A FT0716
944 43A, 70A, 77J, 87J FT0719-2
950 90A, 99A, 58H, 15J, 43J, 73J, 81J, 31K, 49U FT0719-2
966 33A FT0719-2
966B 75A, 57H FT0719-2
966C 78G, 76J, 30K FT0719-2
980 42H FT0723-1
980B 89P FT0719-2
988 87A1-13081 FT0718-1
9888 7A-1309 FT0775-2
988B 50W FT1177-3
992 25K FT0776-1
992C 42X FT1177-3
