Caterpillar Engine Tools Cat Overhaul 3512 Page 368

Operation and Maintenance Manual
2647408
2678791
3-368
Engine Tools
Engine Lifting and Positioning
8F-2550 Engine Tilting Group Parts
Part Number No. Req’d D399,
G399
No. Req’d D398,
G398
No. Req’d D379,
G379
Description Length mm (in) Thread Ends
FT0733-2 3 2 2 Stud 203,2 (8.00) RH
FT0111 3 2 2 Stud 254,0 (10.00) RH
FT0111-A 3 2 2 Stud 520,7 (20.5) RH
FT0733-10 3 2 2 Stud 596,9 (23.5) RH
FT0733-1 3 2 2 Stud 152,4 (6.00) RH, LH
FT0733-5 3 2 2 Stud 292,1 (11.5) RH, LH
FT0733-7 3 2 2 Stud 469,9 (18.5) RH, LH
FT0733-9 3 2 2 Stud 546,1 (21.5) RH, LH
12 8 8 Block
6 4 4 Stud, 368, 3 mm
(1 1/4in - 14 1/2in)
L
6 4 4 Stud, 228, 6 mm
(1 1/4in - 9 in) L
12 8 8 Yoke
6 4 4 Hinge Yoke
6 4 4 Hinge Block
2 2 2 Eyebolt 5/8 in
8F-2550 Engine Tilting Group Parts (Continued)
Part Number No. Req’d D399, G399 No. Req’d D398, G398 No. Req’d D379, G379 Description
5B-1181¹ 6 4 4 Turnbuckle
FT0731 1 Support Beam, LH
FT0735 1 Support Beam, RH
FT0734 6 4 4 Support Beam
FT0736 6 4 4 Support Bracket
FT0732 2 2 2 Lifting Channel
FT0113A 1 1 Support Beam
FT0113 1 1 Support Beam
2 2 Guide Pin, 254 mm (7/8 -
NF) long
2 Guide Pin 254 mm (1 in -
NF, 10 in) long
2 2 2 Small Hoist
¹ Discontinued, part of the 8F-2550 Engine Tilting Group
Part Number
No. Reqd: D399,
G399
No. Reqd: D398,
G398
No. Reqd: D379,
G379 Description Size
0S-1587 18 12 12 Bolt 12.7 - 44.45 mm (1/2 - 1
3/4 in) long
1B-4334
1
12 8 8 Nut 1 1/4in
5F-9892
1
30 20 20 Coupling Pin (70 ton) --
3B-4618 60 40 40 Cotter Pin --
1D-4609 12 8 8 Bolt 19.05 - 76.2 mm (3/4 - 3
in) long
1A-5964 12 8 8 Bolt 9.53 - 114.3 mm (3/8 - 4.5
in) long
(Continued)
