Caterpillar Engine Tools Cat Overhaul 3512 Page 203

Operation and Maintenance Manual
2593852
3-203
Engine Tools
Fuel System Test Tools
158-2262 AVM 2-PC Fuel Injection Equipment Test Stand
Model: Cat
®
Engines
Warranty: Manufacturer’s One Year
European Union compliant, CE marked
Testbenchesarecapableofoperatinginthe380-480Voltrangebutactualvoltagewillbe
checked and or changed during the on-site commissioning by the authorized Hartridge agent.
• Used to test fuel injection system components for pump and line fuel systems on Cat
®
engines
Machine Basics
• AdvancedVideoMetering(AVM)
• Designed to Caterpillar
®
specicationstotestmostinjectionpumpsintheCat
®
product
line (includes all Cat-built pumps, Stanadyne DB2 and DB4 pumps used on 3054 and 3056
pre-emissioncertiedengines,andZexelandNippondensopumpsusedon3046,3064,and
3066)
• Stanadyne,Lucas,andBoschemissioncertiedpumpsmaynotbeservicedbyCat
®
deal-
ers
• ComplieswithEuropeanCEmarkingdirectiveandconformswithECMstandards
• Basic machine and metering unit complies with ISO4008, EEC, and UL/CSA standards
(pump mounting system, cooled nozzle block, and master nozzles are unique to Cat
®
)
• “DCdrive”andstandardPCarchitectureallowmodemornetworkconnections
• Uses industry standard PC allowing future expansion
• Usesadirectdrive,high-torque,15kW(20Hp)DCmotorforlowRPMperformance
• Anon-boardairsupplywithelectronicreadoutisavailableforsettingFARCcontrols
• Electronic dynamic phasing
• Auto Step test plan editor and execution
• Pressure phasing to 80 bars
• Otherfeaturesare2variableDCsupplies,cooledmeteringunit,backleakagetemperature
measurementatpumpoutlet,analogspeedtrimfornecontrolofgovernors,digitalpres-
suredisplays,drive“nudge”control
• This unit has many common parts currently used with standard Hartridge benches, result-
ing in product support from Delphi Diesel Systems Worldwide
Machine Displays
• Controlpanelpivotstopermitoperationfromeithersideofteststand
• Displaymodesinclude;speed,pumpoutput,phasingangle,pressureandteststandself
diagnostic information
• Withexceptionofoilpressurecontrolvalvesandemergencystopbuttons,abuilt-incom-
puter and keyboard control test stand with user friendly Windows
®
• Pump output and test stand operating data are displayed on a 38 cm (15 in) color monitor
Nozzle Block
• Cooled nozzle block dissipates heat, at its source, from high-energy Cat
®
fuel pumps
• Articulatedsupportarmpivotsbeneathfrontoftable,allowingmasternozzlemounttobe
repositioned without disturbing pump mounting brackets
• Underslungmulti-positionmasternozzlemounthasverticaladjustment
Injection Pump Mounting Information
• Standard Cat
®
pump mounting rail uses existing mounting accessories and hardware (not
included)
Testing
• “Intelligent Firing Order Learning” allows pump to be connected to test injectors in most
convenientway
• Drivesystemautomaticallycompensatesforloadvariations(providesaconstant,pre-
selectable test speed within a range of 30 to 4000 RPM
• Allconnectionsandassociatedvalvesaregroupedtogetheronthebulkhead,leavinga
largeunobstructed,self-drainingworkareaatfrontoftablefortoolsandttings
• PowerfulHewlett-Packardcomputercontrolledplatformisexible,andupgradeableto
meetfuturerequirementsandprovidesaccuratemeteringandinformationmanagement/
documentationcapabilitiesprovidecompliancewithcurrentemissionsandISOstandards
(Continued)
