3-230

Engine Tools

Fuel System Test Tools

Section B-B

Item Part Number Description Qty.

15 9S-4182 Plug 2

16 6V-5048 Seal 2

17 and 18 9F-2247 Pipe Plug 2

4C-8740 Air Supply and Test Group

Item Description

6 9.53 mm (3/8 in) Tubing, 0.46 m (1.5 ft)

7 Air Bulb (W.A. Baum Co. Inc. Catalog No.

1890)

Item Part Number Description Size Qty.

1 8T-0841 Plastic Case -- --

2 8T-0839 Diff Pressure Gauge -- --

3 9U-6100 Gauge -- --

4 4C-3974 Union Fitting -- 4

5 1U-5469 Pressure Gauge -- --

-- 4C-8740 Air Supply and Test

Group

-- --

Not Shown

-- 8T-0821 Tubing 16 m (52.5 ft) --

-- 4C-3973 Fitting 3.18 x 3.18 mm (1/8

x 1/8in)

-- 3J-7354 O-ring Seal -- 2

-- 5D-9231 Fitting -- 2

Also not shown: Male Connector, 6.35 x 3.18 mm (1/4x 1/8in) (Qty. 2) and Bulkhead Union, 3.18 mm (1/8in) (Qty. 2)
