Engine Tools

Cylinder Head, Valves and Cam Followers

Cylinder Condition Analysis Tools (Continued)

Model: All Models

Warranty: Six Months

Item Part Number Description

1 6K-5875 Hose Assembly

2 1P-5564 Adapter (D.I. Engines)

3 1P-5565 Adapter (Gas Engines)

5 3B-7767 Nipple (Modify nipple

byllingwithbrazeand

drilling a 1.02 mm (0.04 in)

oriceholethroughbraze)

6 3B-7762 Tee Fitting

7 6V-4142 Nipple,Unvalved(for42000

kPa)

Item Part Number Description

8 9S-7341 Fitting [6.35 mm ( 1/4 in)

tube, 3.175 mm ( 1/8 in)

pipe]

9 8S-2268 Tube Assembly

10 6V-4143 Coupler Assembly

10 7S-8897 Seal

11 8T-0846 Pressure Gauge

12 1P-5569 Tip

13 1P-5567 Tip

Not Shown

-- 5K-5068 Nipple - Pipe Hexagon

9U-7995 Head Guide Pin

Model: 3046 Diesel Engine

Warranty: Six Months

• Used to align cylinder head during

engine assembly — two required

• Simple to use (threaded guide pin

hasscrewdriverslotforeasyinstal-

lation)

• Thread: M12 x 1.75

• Overalllength:115.0mm(4.5in)

Reference

SENR6458, Special Instruction, Disas-

sembly and Assembly of 3046 Engine

Part Number Description

9U-7995 Head Guide Pin

312-2840 Socket (Head and Flywheel Bolt)

Model: C175

Warranty: Six Months

• Usedtoremoveandinstallcylinder

headandywheelbolts

• Usedwith3/4inchdrivestandard

and torque wrenches

• Do not use with impact wrench

• Heavy-duty,twelve-pointsocket

properlytsM16Bolts(24mm

acrossats)

References

KENR6052,ServiceManual,C175-16

and C175-20 Engine, Disassembly and

Assembly

RENR7466,ServiceManual,C175-16

Generator Engine Sets, Disassembly and

Assembly

Part Number Description

312-2840 Socket (Head and

Flywheel Bolt)
