Caterpillar Engine Tools Cat Overhaul 3512 Page 204

Operation and Maintenance Manual
2593852
2648027
3-204
Engine Tools
Fuel System Test Tools
158-2262 AVM 2-PC Fuel Injection Equipment Test Stand (Continued)
Model: Cat
®
Engines
Warranty: Manufacturer’s One Year
• High-speed,12-cylinderadvancedmeteringsystemreducestesttime
Operation
• Controlconsolepivotstopermitoperationfromeithersideofteststand
• Keyboard height and angle are set to minimize strain
• Floppy and CD-ROM can be accessed from front of machine
• Computerandkeyboardallowoperatortoenterdata(speed)andobserveresults(pump
output) on display
• All functions are menu controlled
• On-screen“analog”pressuregauges,arstinthetestbenchmarket,allowsviewing
trendsandrelativemeasurementswhiledisplayingnumericalvalueforaccuratesetting
• Dynamic phasing display shows all pump phasing angles (±0.1°) simultaneously for rapid
adjustment
• Self-diagnosticfunctionwillindicatemotorover/temperature,airsupplyfailure,dirtylter,
stalledmotor,andlowtanklevels
• Built-in PC allows test data to be stored on standard database software or print to color
printer(notincluded).Operatingdatasuchastestplanscanbeentered,stored,removed
and executed
Service
• Built-in, self-diagnostic routines are used to detect internal machine problems, with faults
and test results displayed on LCD screen
• All electronic circuits use solid state technology and feature simple plug-in replacement
boards
• All test oil supply and lube system components are located on left-hand side of bench
• Allelectricalandelectronicservicesareonrightsideofbench
Worldwide Compatibility
• Machineshavemultiplelanguagecapability(currentlanguagechoicesareDutch,English,French,German,Greek,Italian,
Portuguese, Spanish, and Turkish)
• The machines include the Manual on CD-ROM in the following languages: Dutch, English, French, German, Greek, Italian,
Portuguese, Spanish, and Turkish
• BenchisCSA-approved
• BenchmeetsapplicableCEdirectiveswhenon-sitecommissioningiscompleted
Repair Information
If test stand needs more than general maintenance or adjusting, contact original equipment manufacturer at the following loca-
tions.
Hartridge Limited
The Hartridge Building
Network 421
RadcliveRoad
Buckingham
MK18 4FD
U.K.
Switchboard: 44 (0) 1280 825 600
Fax: 44 (0) 1280 825 601
Service24-Hour:44(0)1280825650
ServiceFax:44(0)1280825675
ServiceE-mailaddress:support@hartridge.com
Web site: www.hartridge.com
Reference
NEHS0724, Tool Operating Manual (included with bench — may be ordered separately)
Ordering Information
• Testbenchesarecapableofoperatinginthe380-480Voltrange,butactualvoltagewillbecheckedandorchangedduring
theon-sitecommissioningbytheauthorizedHartridgeagent.On-sitestartupisprovidedbythemanufacturer.For220to240
voltapplications,atransformerisrequired.
(Continued)
