Caterpillar Engine Tools Cat Overhaul 3512 Page 177

Operation and Maintenance Manual
2593365
2593387
2593401
3-177
Engine Tools
Lube System
4C-6780 Bushing Removal Tool Group
Model: 3208 Engines
Warranty: Six Months
• Removesoilpumpbushingfastwithoutdamagingtiminggearcover
• Works on both naturally aspirated and turbo-charged engines
• Marked for each engine for easy use
Item Part Number Description
-- 4C-6780 BushingRemovalTool
Group
Service/Repair Parts
1 4C-6781 BushingRemovalGuide
2 4C-6782 BushingRemovalPunch
FT0977 Oil Pump and Pan Removal and Installation Tool
Model: 992 Engine
Warranty: None
• Usedtoremoveoilpumpandpanasauniton992
• Material: SAE 1020 steel
9S-9273 Coupler
9S-9274 Plug
Model: D8H, 583H, D9G, DD9G, 594
Warranty: Six Months
• Couplerisquickdisconnectadapterforequipmentthatserviceshighspeedoil
changeattachmentgroups;highspeedoilchangegroupsprovideconvenient
methodforbothllandevacuationofenginecrankcaseoil,andacompatible
quickdisconnectcouplerisessentialforserviceequipmentthatsuppliesand
evacuatesoil
• Minimal chance for airborne contaminates to enter engine during oil changes
with high speed oil change arrangement
• Threedifferentnipplesareusedinvariousattachmentgroups;9S-9273Coupler
accommodatesallthree;steelcablelanyardprovidedfordisconnectingcoupler
from nipple
• 9S-9274 Plug Assembly used to protect coupler from dirt and other contami-
nants when not in use
• Easierforcustomertomeetlocalregulationsconcerningoilspillage;leakproof
sealcreatedwhencouplerconnectedtonipple;also,noleakageoccurswhen
coupler engages nipple or when connection is broken
(Continued)
