3-272

Engine Tools

Fuel System Repair and Adjust

Tools for Accessory Drive Gear

Model: 3204 Vehicular Engines

Warranty: None

• 4fabricatedtoolsneededtoloosenaccessorydrivegearfromshaftwithout

removingradiatoron3204VehicularEngines

• FT1537 Socket and FT1539 Puller used on 45V Vehicular Engines

• FT1537 Socket, FT1538 Puller and FT1540 Puller used on 10X Vehicular Engines

• 8H-8561 Adapter and 5P-8676 Extension also required

Item Part Number Description

1 FT1539 Puller

2 FT1540 Puller

4 FT1538 Puller

6 FT1823 Socket

Item Part Number Description

3 8H-8561 Adapter

5 5P-8676 Extension

9S-8520 Puller Group

Discontinued — Service Parts Available

ServicePartsWarranty:SixMonths

Item Part Number Description

1 9S-8527 Bolt

2 5P-3031 Thrust Washer

3 9S-8528 Bolt Assembly

-- 9S-8520 Puller Group

FT0887 Timing Pin

Model: 1100, 3100

Warranty: None

• Used to set timing dimensions on 1100 and 3100 Series

Engines

• Canbeusedwithoutremovingfuellinesandairinletpipe
