Caterpillar Engine Tools Cat Overhaul 3512 Page 285

Operation and Maintenance Manual
2596974
2597003
3-285
Engine Tools
Fuel System Repair and Adjust
5P-6577 Fuel Setting Tool Group
Model: Cat
®
Engines
Warranty: Six Months
• Contains only those tools needed for checking and adjusting fuel setting on
engineswithSleeveMeteringFuelSystems
• Alltoolsinthisgroupalsocontainedin5P-4203FieldServiceToolGroup
Item Part Number Description
1 1D-4533 Bolt
2 1D-4538 Bolt
3 5P-4205 Wrench
1
4 3P-1544 Pin
5 3J-6956 Spring
6 5P-0299 Pin
7 5P-0298 Pin
8 5P-6602 Adapter
8 3P-1565 Collet Clamp
8 3P-1567 Indicator
8 8S-7271 Setscrew
8
2
5P-6531 Point
9 5P-7319 Box
-- 5P-6577 Fuel Setting Tool Group
1
Warranty: Six Months
2
Part of 3P-1567
Calibration Tools
Model:3208EngineswithHeavySleeveMeteringFuelSystem
Warranty: Six Months
• Usedtoset,test,andadjustheavysleevemeteringfuelpumps—thesetoolsarenotavailableasagroupandshouldbe
ordered to supplement existing tool groups
• Usedwith3P-2200SleeveMeteringCalibrationToolGroup,5P-4203SleeveMeteringFieldServiceToolGroup,and5P-6577
Fuel Setting Tool Group
• The3P-1565Collet,8S-7271Setscrew,and3J-6956Springarerequiredforthisoperationandarepartof5P-4203Sleeve
MeteringFieldServiceToolGroupor5P-6577FuelSettingToolGroup
• A6V-6082Bit,5/64Hex,partof6V-4980TorqueScrewdriverToolGroup,isrequiredfor8S-7271Setscrewtoadjusttheinjec-
tion pumps
• 146-5068 Hex Key required for on engine adjustment for aftercooled engines
• Alltoolscanbestoredina6V-3073Case;6V-4094foam(convoluted)isusedinthelid;twofoamblocksn>arerequiredinthe
casebottom,6V-4873toppedwith2P-8289(convoluted);allfoamiscuttotthecase
References
REHS0063,SpecialInstructions,SleeveSetting
SENR3688,ServiceManual
Item Description
5 OriginalLoadStopCoverBolts
(Continued)
