Engine Tools
Crankshaft, Main Bearings and Flywheel
Crankshaft Seal and Wear Sleeve Installation Tools (Silicone and Hydrodynamic) (Continued)
Model: 1100, 3100, 3200, 3300, 3400
Warranty: Six Months
CURRENT ENGINES
Item Location Part Number Description Qty.
3114 and 3116 Engines - Hydrodynamic Seals - SMHS8508,
SEHS8868 (Continued)
5 Front and
Rear
9S-8858 Nut Assembly --
6 Rear 1U-7596 ModiedbyCat
®
Bolt
--
-- -- 171-7212 WearSleeve --
-- Front and
Rear
5P-7312 Distorter --
-- Rear 4C-4869 Distorter Ring --
-- -- 5P-6208 WearSleeve
Installer
--
3114, 3116 and 3126 HEUI Engines - Hydrodynamic Seals -
SMHS8508
1 Rear 132-8772 Locator 2
2 Front 1U-7430 Front Crank Seal
Installer
--
2 Rear 1U-7594 Rear Installer --
3, 4 Rear 1U-7597 SleeveRing --
5 Front and
Rear
9S-8858 Nut Assembly --
6 Rear 1U-7596 ModiedbyCat
®
Bolt
--
-- -- 171-7212 WearSleeve --
-- Front and
Rear
5P-7312 Distorter --
-- Rear 4C-4869 Distorter Ring --
-- -- 5P-6208 WearSleeve
Installer
--
3176, 3196, C-10 and C-12
3
-- Front 145-5247 WearSleeve
Installer
--
-- Front 9Y-0821 WearSleeve --
-- Rear 9Y-0810 WearSleeve --
-- Rear 147-2675 WearSleeve
Installer
--
3400 Engines - Silcon Seals - SMHS7100
1 Front and
Rear
5P-1733 Locator --
1 Rear 5P-7301 Locator --
2 Front 6V-2086 Installer --
2 Rear 6V-2087 Installer --
5 Front and
Rear
9S-8858 Nut Assembly --
6 Front and
Rear
5P-1737 Bolt 3
CURRENT ENGINES
Item Location Part Number Description Qty.
3400 Engines - Silcon Seals - SMHS7100 (Continued)
6 Rear 5P-7310 Bolt 2
6 Rear 5P-7309 Bolt 2
-- Front and
Rear
5P-7314 Distorter Ring --
-- Front and
Rear
5P-7312 Distorter --
3400 Engines - Hydrodynamic Seals - SMHS8508
1 Front and
Rear
5P-1733 Locator --
1 Rear 5P-3594 Locator --
1 Rear 5P-7301 Locator --
2 Front 6V-6142 Installer --
2 Rear 8T-2855 Installer --
2 Rear 8T-2683 Installer --
2 Rear 6V-6143 Installer --
3, 4 Rear 8T-2856 Other Part --
5 Front and
Rear
9S-8858 Nut Assembly --
6 Front and
Rear
5P-1737 Bolt 3
6 Rear 5P-7309 Bolt 2
6 Rear 1T-0720 Bolt 2
6 Rear 5P-7310 Bolt 2
-- Front and
Rear
5P-7314 Distorter Ring --
-- Front and
Rear
5P-7312 Distorter --
-- Rear 5P-7409 SleeveDistorter --
3500 Engines - Hydrodynamic Seals - SMHS8508
1 Front and
Rear
6V-4003 Locator --
1 Rear 192-6339 Crankshaft Seal
Locator Assembly
--
2 Front and
Rear
8T-3099 Installer --
2 Front and
Rear
6V-4977 Installer --
2 Rear 187-1841 Seal And Wear
SleeveInstaller
--
3, 4 Front and
Rear
6V-4001 Other Part --
3, 4 Front and
Rear
6V-4002 Other Part --
5 Front and
Rear
9S-8858 Nut Assembly --
(Continued)
