Engine Tools

Fuel System Repair and Adjust

5P-6217 Fixture

5P-6218 Bearing Driver

Model: 3408, 3412

Warranty: Six Months

• Used to install tanged fuel rack

bearings on 3408 and 3412 Engines

Part Number Description

5P-6217 Fixture

5P-6218 BearingDriver

FT1251 Pump Housing Stand

Model: Cat

Engines

Warranty: None

• Fuelsystemcomponentsconvenientlyservicedonthisstand

• HasrailsthattholdingxturefromFuelInjectionTestBench;byusingap-

propriateFITBadapterplateandholdingxture,injectionpumphousingscan

bemountedonstandfordisassemblyandassembly,theneasilymovedtoTest

Benchfornaladjustmentandtesting

FT0960 Adapter Assembly

Model: 4.75 inch Bore Engines

Warranty: None

• Used to hold fuel rack in centered position when installing fuel pumps on all

12.07 cm (4.75 in) bore engines with compact fuel systems except D334 and 1674

Engines

• Material: mild steel
