CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 87

Operation and Maintenance Manual
Product: SKID STEER LOADER
Model: 226B SKID STEER LOADER MJH
Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574
(MACHINE) POWERED BY 3024C Engine
Operation and Maintenance Manual
216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders
Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007
i01947113
Plate Locations and Film Locations
SMCS - 1000; 7000
The Product Identification Number (PIN) will be used to identify a powered machine that is designed for an
operator to ride.
Caterpillar products such as engines, transmissions and motorized work tools that are not designed for an
operator to ride are identified by Serial Numbers.
For quick reference, record the identification numbers in the spaces that are provided below the illustration.
Illustration 1 g00902931
247 267 277
