Failures that result from extended oil drain periods are not Caterpillar factory defects and therefore are not

covered by Caterpillar's warranty. In addition, failures that result from not using the recommended oil type

are not Caterpillar factory defects and therefore are not covered by Caterpillar's warranty.

Refer to the applicable Operation and Maintenance Manual for standard oil drain periods and to the

Maintenance Section, "Lubricant Specifications" of this publication for engine oil type and viscosity grade

recommendations.

To reduce the potential risk of failures associated with extended oil drain periods; it is recommended that

oil drain intervals only be extended based on oil analysis, and subsequent engine inspections. Oil analysis

alone does not provide an indication of the rate of formation of lacquer, varnish and/or carbon on pistons

and other engine surfaces. The only accurate way to evaluate specific oil performance in a specific engine

and application that utilizes extended oil drain periods is to observe the effects on the engine components.

This involves tear-down inspections of engines that have run to their normal overhaul period with extended

oil drain intervals. Following this recommendation will help ensure that excessive component wear does not

take place in a given application.

NOTICE

Light loads, low hour accumulation, and excessive idling

time can contribute to excessive water in the crankcase oil.

Corrosive damage, piston deposits and increased oil

consumption can also result. If oil analysis is not done or

the results are ignored, the potential for corrosive damage

and piston deposits increases. Refer to the appropriate

Operation and Maintenance Manual for guidance.

Note: Failures that result from extended oil drain periods are not warrantable failures, regardless of use of

this recommended procedure. Failures that result from extended engine oil drain periods are considered

improper use under the warranty.

Aftermarket Products and Warranty

NOTICE

When auxiliary devices, accessories or consumables (filters,

oil, additives, catalysts, fuel, etc.) made by other

manufacturers are used on Caterpillar products, the

Caterpillar warranty is not affected simply because of such

use. Failures that result from the installation or usage of

other manufacturers auxiliary devices, accessories or

consumables, however, are not Caterpillar factory defects

and therefore are NOT covered by Caterpillar's warranty.

Caterpillar is not in a position to evaluate the many

auxiliary devices, accessories or consumables promoted by

other manufacturers and their effect on Caterpillar

products. Installation or use of such items is at the

discretion of the customer who assumes ALL risks for the

effects that result from this usage.

Furthermore, Caterpillar does not authorize the use of its
